Zelda 3 specific classes and functions. More...

Namespaces
namespace	anonymous_namespace{hyrule_magic.cc}

namespace	anonymous_namespace{overworld.cc}

namespace	anonymous_namespace{tracker.cc}

namespace	music
	Contains classes and functions for handling music data in Zelda 3.

namespace	palette_internal

Classes
struct	DungeonMap

class	DungeonObjectRenderer

class	GameEntity
	Base class for all overworld and dungeon entities. More...

class	Inventory

struct	LayerMergeType

class	Overworld
	Represents the full Overworld data, light and dark world. More...

class	OverworldEntrance

struct	OverworldEntranceTileTypes

class	OverworldExit

class	OverworldItem

class	OverworldMap
	Represents a single Overworld map screen. More...

struct	OverworldMapTiles
	Overworld map tile32 data. More...

struct	PseudoVram

class	Renderer
	The Renderer class represents the renderer for the Yaze application. More...

class	Room

class	RoomEntrance
	Dungeon Room Entrance or Spawn Point. More...

class	RoomObject

class	Sprite
	A class for managing sprites in the overworld and underworld. More...

class	SpriteAction

class	SpriteBuilder

class	SpriteInstruction

class	Subtype1

class	Subtype2

class	Subtype3

struct	SubtypeInfo

class	TitleScreen

Typedefs
using	OverworldBlockset = std::vector<std::vector<uint16_t>>
	Represents tile32 data for the overworld.

typedef struct yaze::zelda3::OverworldMapTiles	OverworldMapTiles
	Overworld map tile32 data.

Enumerations
enum class	SpecialObjectType { Chest , BigChest , InterroomStairs }

enum	Sorting { All = 0 , Wall = 1 , Horizontal = 2 , Vertical = 4 , NonScalable = 8 , Dungeons = 16 , Floors = 32 , SortStairs = 64 }

enum class	ObjectOption { Nothing = 0 , Door = 1 , Chest = 2 , Block = 4 , Torch = 8 , Bgr = 16 , Stairs = 32 }

enum	CollisionKey { One_Collision , Both , Both_With_Scroll , Moving_Floor_Collision , Moving_Water_Collision }

enum	EffectKey { Effect_Nothing , One , Moving_Floor , Moving_Water , Four , Red_Flashes , Torch_Show_Floor , Ganon_Room }

enum	TagKey { Nothing , NW_Kill_Enemy_to_Open , NE_Kill_Enemy_to_Open , SW_Kill_Enemy_to_Open , SE_Kill_Enemy_to_Open , W_Kill_Enemy_to_Open , E_Kill_Enemy_to_Open , N_Kill_Enemy_to_Open , S_Kill_Enemy_to_Open , Clear_Quadrant_to_Open , Clear_Room_to_Open , NW_Push_Block_to_Open , NE_Push_Block_to_Open , SW_Push_Block_to_Open , SE_Push_Block_to_Open , W_Push_Block_to_Open , E_Push_Block_to_Open , N_Push_Block_to_Open , S_Push_Block_to_Open , Push_Block_to_Open , Pull_Lever_to_Open , Clear_Level_to_Open , Switch_Open_Door_Hold , Switch_Open_Door_Toggle , Turn_off_Water , Turn_on_Water , Water_Gate , Water_Twin , Secret_Wall_Right , Secret_Wall_Left , Crash1 , Crash2 , Pull_Switch_to_bomb_Wall , Holes_0 , Open_Chest_Activate_Holes_0 , Holes_1 , Holes_2 , Kill_Enemy_to_clear_level , SE_Kill_Enemy_to_Move_Block , Trigger_activated_Chest , Pull_lever_to_Bomb_Wall , NW_Kill_Enemy_for_Chest , NE_Kill_Enemy_for_Chest , SW_Kill_Enemy_for_Chest , SE_Kill_Enemy_for_Chest , W_Kill_Enemy_for_Chest , E_Kill_Enemy_for_Chest , N_Kill_Enemy_for_Chest , S_Kill_Enemy_for_Chest , Clear_Quadrant_for_Chest , Clear_Room_for_Chest , Light_Torches_to_Open , Holes_3 , Holes_4 , Holes_5 , Holes_6 , Agahnim_Room , Holes_7 , Holes_8 , Open_Chest_for_Holes_8 , Push_Block_for_Chest , Kill_to_open_Ganon_Door , Light_Torches_to_get_Chest , Kill_boss_Again }

Functions
ObjectOption	operator\| (ObjectOption lhs, ObjectOption rhs)

ObjectOption	operator& (ObjectOption lhs, ObjectOption rhs)

ObjectOption	operator^ (ObjectOption lhs, ObjectOption rhs)

ObjectOption	operator~ (ObjectOption option)

SubtypeInfo	FetchSubtypeInfo (uint16_t object_id)

void	stle16b_i (uint8_t *const p_arr, size_t const p_index, uint16_t const p_val)
	Store little endian 16-bit value using a byte pointer, offset by an index before dereferencing.

void	stle16b (uint8_t *const p_arr, uint16_t const p_val)

uint16_t	ldle16b (uint8_t const *const p_arr)

uint16_t	ldle16b_i (uint8_t const *const p_arr, size_t const p_index)
	Load little endian halfword (16-bit) dereferenced from an arrays of bytes. This version provides an index that will be multiplied by 2 and added to the base address.

absl::StatusOr< OverworldEntranceTileTypes >	LoadEntranceTileTypes (Rom &rom)

absl::Status	LoadDungeonMapGfxFromBinary (Rom &rom, std::array< gfx::Bitmap, 4 > &sheets, gfx::Tilesheet &tile16_sheet, std::vector< uint8_t > &gfx_bin_data)

absl::Status	LoadDungeonMapTile16 (const std::vector< uint8_t > &gfx_data, bool bin_mode)

Variables
constexpr std::string_view	kEntranceNames []

constexpr int	kGfxBufferOffset = 92 * 2048

constexpr int	kGfxBufferStride = 512

constexpr int	kGfxBufferAnimatedFrameOffset = 7 * 2048

constexpr int	kGfxBufferAnimatedFrameStride = 512

constexpr int	kGfxBufferRoomOffset = 2048

constexpr int	kGfxBufferRoomSpriteOffset = 512

constexpr int	kGfxBufferRoomSpriteStride = 2048

constexpr int	kGfxBufferRoomSpriteLastLineOffset = 0x88

constexpr int	room_object_layout_pointer = 0x882D

constexpr int	room_object_pointer = 0x874C

constexpr int	dungeons_main_bg_palette_pointers = 0xDEC4B

constexpr int	dungeons_palettes = 0xDD734

constexpr int	room_items_pointers = 0xDB69

constexpr int	rooms_sprite_pointer = 0x4C298

constexpr int	kRoomHeaderPointer = 0xB5DD

constexpr int	kRoomHeaderPointerBank = 0xB5E7

constexpr int	gfx_groups_pointer = 0x6237

constexpr int	chests_length_pointer = 0xEBF6

constexpr int	chests_data_pointer1 = 0xEBFB

constexpr int	messages_id_dungeon = 0x3F61D

constexpr int	blocks_length = 0x8896

constexpr int	blocks_pointer1 = 0x15AFA

constexpr int	blocks_pointer2 = 0x15B01

constexpr int	blocks_pointer3 = 0x15B08

constexpr int	blocks_pointer4 = 0x15B0F

constexpr int	torch_data = 0x2736A

constexpr int	torches_length_pointer = 0x88C1

constexpr int	sprite_blockset_pointer = 0x5B57

constexpr int	sprites_data = 0x4D8B0

constexpr int	sprites_data_empty_room = 0x4D8AE

constexpr int	sprites_end_data = 0x4EC9E

constexpr int	pit_pointer = 0x394AB

constexpr int	pit_count = 0x394A6

constexpr int	doorPointers = 0xF83C0

constexpr int	door_gfx_up = 0x4D9E

constexpr int	door_gfx_down = 0x4E06

constexpr int	door_gfx_cavexit_down = 0x4E06

constexpr int	door_gfx_left = 0x4E66

constexpr int	door_gfx_right = 0x4EC6

constexpr int	door_pos_up = 0x197E

constexpr int	door_pos_down = 0x1996

constexpr int	door_pos_left = 0x19AE

constexpr int	door_pos_right = 0x19C6

constexpr int	dungeon_spr_ptrs = 0x090000

constexpr int	NumberOfRooms = 296

constexpr uint16_t	stairsObjects [] = {0x139, 0x138, 0x13B, 0x12E, 0x12D}

constexpr std::string_view	kRoomNames []

constexpr int	kEntranceRoom = 0x14813

constexpr int	kEntranceScrollEdge = 0x1491D

constexpr int	kEntranceYScroll = 0x14D45

constexpr int	kEntranceXScroll = 0x14E4F

constexpr int	kEntranceYPosition = 0x14F59

constexpr int	kEntranceXPosition = 0x15063

constexpr int	kEntranceCameraYTrigger = 0x1516D

constexpr int	kEntranceCameraXTrigger = 0x15277

constexpr int	kEntranceBlockset = 0x15381

constexpr int	kEntranceFloor = 0x15406

constexpr int	kEntranceDungeon = 0x1548B

constexpr int	kEntranceDoor = 0x15510

constexpr int	kEntranceLadderBG = 0x15595

constexpr int	kEntrancescrolling = 0x1561A

constexpr int	kEntranceScrollQuadrant = 0x1569F

constexpr int	kEntranceExit = 0x15724

constexpr int	kEntranceMusic = 0x1582E

constexpr int	kStartingEntranceroom = 0x15B6E

constexpr int	kStartingEntranceScrollEdge = 0x15B7C

constexpr int	kStartingEntranceYScroll = 0x15BB4

constexpr int	kStartingEntranceXScroll = 0x15BC2

constexpr int	kStartingEntranceYPosition = 0x15BD0

constexpr int	kStartingEntranceXPosition = 0x15BDE

constexpr int	kStartingEntranceCameraYTrigger = 0x15BEC

constexpr int	kStartingEntranceCameraXTrigger = 0x15BFA

constexpr int	kStartingEntranceBlockset = 0x15C08

constexpr int	kStartingEntranceFloor = 0x15C0F

constexpr int	kStartingEntranceDungeon = 0x15C16

constexpr int	kStartingEntranceDoor = 0x15C2B

constexpr int	kStartingEntranceLadderBG = 0x15C1D

constexpr int	kStartingEntrancescrolling = 0x15C24

constexpr int	kStartingEntranceScrollQuadrant = 0x15C2B

constexpr int	kStartingEntranceexit = 0x15C32

constexpr int	kStartingEntrancemusic = 0x15C4E

constexpr int	kStartingEntranceentrance = 0x15C40

constexpr int	items_data_start = 0xDDE9

constexpr int	items_data_end = 0xE6B2

constexpr int	initial_equipement = 0x271A6

constexpr int	chests_backupitems = 0x3B528

constexpr int	chests_yoffset = 0x4836C

constexpr int	chests_xoffset = 0x4836C + (76 * 1)

constexpr int	chests_itemsgfx = 0x4836C + (76 * 2)

constexpr int	chests_itemswide = 0x4836C + (76 * 3)

constexpr int	chests_itemsproperties = 0x4836C + (76 * 4)

constexpr int	chests_sramaddress = 0x4836C + (76 * 5)

constexpr int	chests_sramvalue = 0x4836C + (76 * 7)

constexpr int	chests_msgid = 0x442DD

constexpr int	dungeons_startrooms = 0x7939

constexpr int	dungeons_endrooms = 0x792D

constexpr int	dungeons_bossrooms = 0x10954

constexpr int	bedPositionX = 0x039A37

constexpr int	bedPositionY = 0x039A32

constexpr int	bedPositionResetXLow = 0x02DE53

constexpr int	bedPositionResetXHigh = 0x02DE58

constexpr int	bedPositionResetYLow = 0x02DE5D

constexpr int	bedPositionResetYHigh = 0x02DE62

constexpr int	bedSheetPositionX = 0x0480BD

constexpr int	bedSheetPositionY = 0x0480B8

constexpr int	kRoomObjectSubtype1 = 0x8000

constexpr int	kRoomObjectSubtype2 = 0x83F0

constexpr int	kRoomObjectSubtype3 = 0x84F0

constexpr int	kRoomObjectTileAddress = 0x1B52

constexpr int	kRoomObjectTileAddressFloor = 0x1B5A

constexpr int	kMap32TilesLength = 0x33F0

constexpr int	GravesYTilePos = 0x49968

constexpr int	GravesXTilePos = 0x49986

constexpr int	GravesTilemapPos = 0x499A4

constexpr int	GravesGFX = 0x499C2

constexpr int	GravesXPos = 0x4994A

constexpr int	GravesYLine = 0x4993A

constexpr int	GravesCountOnY = 0x499E0

constexpr int	GraveLinkSpecialHole = 0x46DD9

constexpr int	GraveLinkSpecialStairs = 0x46DE0

constexpr int	kOverworldMapPaletteIds = 0x7D1C

constexpr int	kOverworldSpritePaletteIds = 0x7B41

constexpr int	kOverworldSpritePaletteGroup = 0x75580

constexpr int	kOverworldSpriteset = 0x7A41

constexpr int	kOverworldSpecialGfxGroup = 0x16821

constexpr int	kOverworldSpecialPalGroup = 0x16831

constexpr int	kOverworldSpritesBeginning = 0x4C881

constexpr int	kOverworldSpritesAgahnim = 0x4CA21

constexpr int	kOverworldSpritesZelda = 0x4C901

constexpr int	kAreaGfxIdPtr = 0x7C9C

constexpr int	kOverworldMessageIds = 0x3F51D

constexpr int	kOverworldMusicBeginning = 0x14303

constexpr int	kOverworldMusicZelda = 0x14303 + 0x40

constexpr int	kOverworldMusicMasterSword = 0x14303 + 0x80

constexpr int	kOverworldMusicAgahnim = 0x14303 + 0xC0

constexpr int	kOverworldMusicDarkWorld = 0x14403

constexpr int	kOverworldEntranceAllowedTilesLeft = 0xDB8C1

constexpr int	kOverworldEntranceAllowedTilesRight = 0xDB917

constexpr int	kOverworldMapSize = 0x12844

constexpr int	kOverworldMapSizeHighByte = 0x12884

constexpr int	kOverworldMapParentId = 0x125EC

constexpr int	kOverworldTransitionPositionY = 0x128C4

constexpr int	kOverworldTransitionPositionX = 0x12944

constexpr int	kOverworldScreenSize = 0x1788D

constexpr int	kOverworldScreenSizeForLoading = 0x4C635

constexpr int	kOverworldScreenTileMapChangeByScreen1 = 0x12634

constexpr int	kOverworldScreenTileMapChangeByScreen2 = 0x126B4

constexpr int	kOverworldScreenTileMapChangeByScreen3 = 0x12734

constexpr int	kOverworldScreenTileMapChangeByScreen4 = 0x127B4

constexpr int	kOverworldMapDataOverflow = 0x130000

constexpr int	kTransitionTargetNorth = 0x13EE2

constexpr int	kTransitionTargetWest = 0x13F62

constexpr int	overworldCustomMosaicASM = 0x1301D0

constexpr int	overworldCustomMosaicArray = 0x1301F0

constexpr int	kMap16TilesExpanded = 0x1E8000

constexpr int	kMap32TileTRExpanded = 0x020000

constexpr int	kMap32TileBLExpanded = 0x1F0000

constexpr int	kMap32TileBRExpanded = 0x1F8000

constexpr int	kMap32TileCountExpanded = 0x0067E0

constexpr int	kMap32ExpandedFlagPos = 0x01772E

constexpr int	kMap16ExpandedFlagPos = 0x02FD28

constexpr int	kOverworldEntranceExpandedFlagPos = 0x0DB895

constexpr int	kOverworldCompressedMapPos = 0x058000

constexpr int	kOverworldCompressedOverflowPos = 0x137FFF

constexpr int	kNumTileTypes = 0x200

constexpr int	kMap16Tiles = 0x78000

constexpr int	kNumOverworldMaps = 160

constexpr int	kNumTile16Individual = 4096

constexpr int	Map32PerScreen = 256

constexpr int	NumberOfMap16 = 3752

constexpr int	NumberOfMap16Ex = 4096

constexpr int	LimitOfMap32 = 8864

constexpr int	NumberOfOWSprites = 352

constexpr int	NumberOfMap32 = Map32PerScreen * kNumOverworldMaps

constexpr int	kNumOverworldEntrances = 129

constexpr int	kNumOverworldHoles = 0x13

constexpr int	kOverworldEntranceMap = 0xDB96F

constexpr int	kOverworldEntrancePos = 0xDBA71

constexpr int	kOverworldEntranceEntranceId = 0xDBB73

constexpr int	kOverworldEntranceMapExpanded = 0x0DB55F

constexpr int	kOverworldEntrancePosExpanded = 0x0DB35F

constexpr int	kOverworldEntranceEntranceIdExpanded = 0x0DB75F

constexpr int	kOverworldHolePos = 0xDB800

constexpr int	kOverworldHoleArea = 0xDB826

constexpr int	kOverworldHoleEntrance = 0xDB84C

constexpr int	kEntranceTileTypePtrLow = 0xDB8BF

constexpr int	kEntranceTileTypePtrHigh = 0xDB917

constexpr int	kNumEntranceTileTypes = 0x2C

constexpr int	kNumOverworldExits = 0x4F

constexpr int	OWExitRoomId = 0x15D8A

constexpr int	OWExitMapId = 0x15E28

constexpr int	OWExitVram = 0x15E77

constexpr int	OWExitYScroll = 0x15F15

constexpr int	OWExitXScroll = 0x15FB3

constexpr int	OWExitYPlayer = 0x16051

constexpr int	OWExitXPlayer = 0x160EF

constexpr int	OWExitYCamera = 0x1618D

constexpr int	OWExitXCamera = 0x1622B

constexpr int	OWExitDoorPosition = 0x15724

constexpr int	OWExitUnk1 = 0x162C9

constexpr int	OWExitUnk2 = 0x16318

constexpr int	OWExitDoorType1 = 0x16367

constexpr int	OWExitDoorType2 = 0x16405

constexpr int	OWExitMapIdWhirlpool = 0x16AE5

constexpr int	OWExitVramWhirlpool = 0x16B07

constexpr int	OWExitYScrollWhirlpool = 0x16B29

constexpr int	OWExitXScrollWhirlpool = 0x16B4B

constexpr int	OWExitYPlayerWhirlpool = 0x16B6D

constexpr int	OWExitXPlayerWhirlpool = 0x16B8F

constexpr int	OWExitYCameraWhirlpool = 0x16BB1

constexpr int	OWExitXCameraWhirlpool = 0x16BD3

constexpr int	OWExitUnk1Whirlpool = 0x16BF5

constexpr int	OWExitUnk2Whirlpool = 0x16C17

constexpr int	OWWhirlpoolPosition = 0x16CF8

constexpr int	kNumOverworldMapItemPointers = 0x80

constexpr int	kOverworldItemsPointers = 0xDC2F9

constexpr int	kOverworldItemsAddress = 0xDC8B9

constexpr int	kOverworldItemsBank = 0xDC8BF

constexpr int	kOverworldItemsEndData = 0xDC89C

const std::vector< std::string >	kSecretItemNames

constexpr int	OverworldCustomASMHasBeenApplied = 0x140145

constexpr int	OverworldCustomAreaSpecificBGPalette = 0x140000

constexpr int	OverworldCustomAreaSpecificBGEnabled = 0x140140

constexpr int	OverworldCustomMainPaletteArray = 0x140160

constexpr int	OverworldCustomMainPaletteEnabled = 0x140141

constexpr int	OverworldCustomMosaicArray = 0x140200

constexpr int	OverworldCustomMosaicEnabled = 0x140142

constexpr int	OverworldCustomAnimatedGFXArray = 0x1402A0

constexpr int	OverworldCustomAnimatedGFXEnabled = 0x140143

constexpr int	OverworldCustomSubscreenOverlayArray = 0x140340

constexpr int	OverworldCustomSubscreenOverlayEnabled = 0x140144

constexpr int	OverworldCustomTileGFXGroupArray = 0x140480

constexpr int	OverworldCustomTileGFXGroupEnabled = 0x140148

constexpr int	kDarkWorldMapIdStart = 0x40

constexpr int	kSpecialWorldMapIdStart = 0x80

constexpr int	kDungeonMapRoomsPtr = 0x57605

constexpr int	kDungeonMapFloors = 0x575D9

constexpr int	kDungeonMapGfxPtr = 0x57BE4

constexpr int	kDungeonMapDataStart = 0x57039

constexpr int	kDungeonMapExpCheck = 0x56652

constexpr int	kDungeonMapTile16 = 0x57009

constexpr int	kDungeonMapTile16Expanded = 0x109010

constexpr int	kDungeonMapBossRooms = 0x56807

constexpr int	kTriforceVertices = 0x04FFD2

constexpr int	kTriforceFaces = 0x04FFE4

constexpr int	kCrystalVertices = 0x04FF98

constexpr int	kInventoryStart = 0x6564A

constexpr int	kBowItemPos = 0x6F631

constexpr const char *	kSpriteProperties []

Detailed Description

Zelda 3 specific classes and functions.

Typedef Documentation

◆ OverworldBlockset

using yaze::zelda3::OverworldBlockset = std::vector<std::vector<uint16_t>>

Represents tile32 data for the overworld.

Definition at line 63 of file overworld_map.h.

◆ OverworldMapTiles

typedef struct yaze::zelda3::OverworldMapTiles yaze::zelda3::OverworldMapTiles

Overworld map tile32 data.

Enumeration Type Documentation

◆ SpecialObjectType

enum class yaze::zelda3::SpecialObjectType

strong

Enumerator
Chest
BigChest
InterroomStairs

Definition at line 22 of file room_object.h.

◆ Sorting

enum yaze::zelda3::Sorting

Enumerator
All
Wall
Horizontal
Vertical
NonScalable
Dungeons
Floors
SortStairs

Definition at line 24 of file room_object.h.

◆ ObjectOption

enum class yaze::zelda3::ObjectOption

strong

Enumerator
Nothing
Door
Chest
Block
Torch
Bgr
Stairs

Definition at line 35 of file room_object.h.

◆ CollisionKey

enum yaze::zelda3::CollisionKey

Enumerator
One_Collision
Both
Both_With_Scroll
Moving_Floor_Collision
Moving_Water_Collision

Definition at line 9 of file room_tag.h.

◆ EffectKey

enum yaze::zelda3::EffectKey

Enumerator
Effect_Nothing
One
Moving_Floor
Moving_Water
Four
Red_Flashes
Torch_Show_Floor
Ganon_Room

Definition at line 17 of file room_tag.h.

◆ TagKey

enum yaze::zelda3::TagKey

Enumerator
Nothing
NW_Kill_Enemy_to_Open
NE_Kill_Enemy_to_Open
SW_Kill_Enemy_to_Open
SE_Kill_Enemy_to_Open
W_Kill_Enemy_to_Open
E_Kill_Enemy_to_Open
N_Kill_Enemy_to_Open
S_Kill_Enemy_to_Open
Clear_Quadrant_to_Open
Clear_Room_to_Open
NW_Push_Block_to_Open
NE_Push_Block_to_Open
SW_Push_Block_to_Open
SE_Push_Block_to_Open
W_Push_Block_to_Open
E_Push_Block_to_Open
N_Push_Block_to_Open
S_Push_Block_to_Open
Push_Block_to_Open
Pull_Lever_to_Open
Clear_Level_to_Open
Switch_Open_Door_Hold
Switch_Open_Door_Toggle
Turn_off_Water
Turn_on_Water
Water_Gate
Water_Twin
Secret_Wall_Right
Secret_Wall_Left
Crash1
Crash2
Pull_Switch_to_bomb_Wall
Holes_0
Open_Chest_Activate_Holes_0
Holes_1
Holes_2
Kill_Enemy_to_clear_level
SE_Kill_Enemy_to_Move_Block
Trigger_activated_Chest
Pull_lever_to_Bomb_Wall
NW_Kill_Enemy_for_Chest
NE_Kill_Enemy_for_Chest
SW_Kill_Enemy_for_Chest
SE_Kill_Enemy_for_Chest
W_Kill_Enemy_for_Chest
E_Kill_Enemy_for_Chest
N_Kill_Enemy_for_Chest
S_Kill_Enemy_for_Chest
Clear_Quadrant_for_Chest
Clear_Room_for_Chest
Light_Torches_to_Open
Holes_3
Holes_4
Holes_5
Holes_6
Agahnim_Room
Holes_7
Holes_8
Open_Chest_for_Holes_8
Push_Block_for_Chest
Kill_to_open_Ganon_Door
Light_Torches_to_get_Chest
Kill_boss_Again

Definition at line 36 of file room_tag.h.

Function Documentation

◆ operator|()

ObjectOption yaze::zelda3::operator\|	(	ObjectOption	lhs,
		ObjectOption	rhs )

Definition at line 6 of file room_object.cc.

◆ operator&()

ObjectOption yaze::zelda3::operator&	(	ObjectOption	lhs,
		ObjectOption	rhs )

Definition at line 11 of file room_object.cc.

◆ operator^()

ObjectOption yaze::zelda3::operator^	(	ObjectOption	lhs,
		ObjectOption	rhs )

Definition at line 16 of file room_object.cc.

◆ operator~()

ObjectOption yaze::zelda3::operator~ ( ObjectOption option )

Definition at line 21 of file room_object.cc.

◆ FetchSubtypeInfo()

SubtypeInfo yaze::zelda3::FetchSubtypeInfo ( uint16_t object_id )

Todo: Determine the subtype based on object_id

Definition at line 25 of file room_object.cc.

References kRoomObjectSubtype1, kRoomObjectSubtype2, kRoomObjectSubtype3, yaze::zelda3::SubtypeInfo::routine_ptr, and yaze::zelda3::SubtypeInfo::subtype_ptr.

◆ stle16b_i()

void yaze::zelda3::stle16b_i	(	uint8_t *const	p_arr,
		size_t const	p_index,
		uint16_t const	p_val )

Store little endian 16-bit value using a byte pointer, offset by an index before dereferencing.

Definition at line 51 of file hyrule_magic.cc.

References stle16b().

Referenced by yaze::zelda3::music::Tracker::SaveSongs().

Here is the call graph for this function:

◆ stle16b()

void yaze::zelda3::stle16b	(	uint8_t *const	p_arr,
		uint16_t const	p_val )

Definition at line 56 of file hyrule_magic.cc.

Referenced by yaze::gfx::HyruleMagicDecompress(), and stle16b_i().

◆ ldle16b()

uint16_t yaze::zelda3::ldle16b ( uint8_t const *const p_arr )

Definition at line 61 of file hyrule_magic.cc.

Referenced by yaze::gfx::HyruleMagicDecompress(), and ldle16b_i().

◆ ldle16b_i()

uint16_t yaze::zelda3::ldle16b_i	(	uint8_t const *const	p_arr,
		size_t const	p_index )

Load little endian halfword (16-bit) dereferenced from an arrays of bytes. This version provides an index that will be multiplied by 2 and added to the base address.

Definition at line 67 of file hyrule_magic.cc.

References ldle16b().

Referenced by yaze::zelda3::music::Tracker::SaveSongs().

Here is the call graph for this function:

◆ LoadEntranceTileTypes()

absl::StatusOr< OverworldEntranceTileTypes > yaze::zelda3::LoadEntranceTileTypes ( Rom & rom )

inline

Definition at line 99 of file overworld_entrance.h.

References ASSIGN_OR_RETURN, yaze::zelda3::OverworldEntranceTileTypes::high, kEntranceTileTypePtrHigh, kEntranceTileTypePtrLow, kNumEntranceTileTypes, yaze::zelda3::OverworldEntranceTileTypes::low, and yaze::Rom::ReadWord().

Referenced by yaze::editor::OverworldEditor::Update().

Here is the call graph for this function:

◆ LoadDungeonMapGfxFromBinary()

absl::Status yaze::zelda3::LoadDungeonMapGfxFromBinary	(	Rom &	rom,
		std::array< gfx::Bitmap, 4 > &	sheets,
		gfx::Tilesheet &	tile16_sheet,
		std::vector< uint8_t > &	gfx_bin_data )

Definition at line 14 of file dungeon_map.cc.

References yaze::gfx::Tilesheet::clear(), yaze::core::Renderer::GetInstance(), LoadDungeonMapTile16(), yaze::Rom::mutable_dungeon_palette(), yaze::core::Renderer::RenderBitmap(), RETURN_IF_ERROR, yaze::core::FileDialogWrapper::ShowOpenFileDialog(), and yaze::gfx::SnesTo8bppSheet().

◆ LoadDungeonMapTile16()

absl::Status yaze::zelda3::LoadDungeonMapTile16	(	const std::vector< uint8_t > &	gfx_data,
		bool	bin_mode )

Referenced by LoadDungeonMapGfxFromBinary().

Variable Documentation

◆ kEntranceNames

std::string_view yaze::zelda3::kEntranceNames[]

constexpr

Definition at line 48 of file common.h.

Referenced by yaze::editor::DungeonEditor::DrawEntranceSelector(), and yaze::editor::OverworldEditor::UpdateUsageStats().

◆ kGfxBufferOffset

int yaze::zelda3::kGfxBufferOffset = 92 * 2048

constexpr

Definition at line 222 of file room.cc.

◆ kGfxBufferStride

int yaze::zelda3::kGfxBufferStride = 512

constexpr

Definition at line 223 of file room.cc.

◆ kGfxBufferAnimatedFrameOffset

int yaze::zelda3::kGfxBufferAnimatedFrameOffset = 7 * 2048

constexpr

Definition at line 224 of file room.cc.

◆ kGfxBufferAnimatedFrameStride

int yaze::zelda3::kGfxBufferAnimatedFrameStride = 512

constexpr

Definition at line 225 of file room.cc.

◆ kGfxBufferRoomOffset

int yaze::zelda3::kGfxBufferRoomOffset = 2048

constexpr

Definition at line 226 of file room.cc.

Referenced by yaze::zelda3::Room::CopyRoomGraphicsToBuffer().

◆ kGfxBufferRoomSpriteOffset

int yaze::zelda3::kGfxBufferRoomSpriteOffset = 512

constexpr

Definition at line 227 of file room.cc.

◆ kGfxBufferRoomSpriteStride

int yaze::zelda3::kGfxBufferRoomSpriteStride = 2048

constexpr

Definition at line 228 of file room.cc.

◆ kGfxBufferRoomSpriteLastLineOffset

int yaze::zelda3::kGfxBufferRoomSpriteLastLineOffset = 0x88

constexpr

Definition at line 229 of file room.cc.

Referenced by yaze::zelda3::Room::CopyRoomGraphicsToBuffer().

◆ room_object_layout_pointer

int yaze::zelda3::room_object_layout_pointer = 0x882D

constexpr

Definition at line 36 of file room.h.

◆ room_object_pointer

int yaze::zelda3::room_object_pointer = 0x874C

constexpr

Definition at line 37 of file room.h.

Referenced by yaze::zelda3::Room::LoadObjects(), and yaze::zelda3::Room::LoadRoomFromROM().

◆ dungeons_main_bg_palette_pointers

int yaze::zelda3::dungeons_main_bg_palette_pointers = 0xDEC4B

constexpr

Definition at line 39 of file room.h.

◆ dungeons_palettes

int yaze::zelda3::dungeons_palettes = 0xDD734

constexpr

Definition at line 40 of file room.h.

◆ room_items_pointers

int yaze::zelda3::room_items_pointers = 0xDB69

constexpr

Definition at line 41 of file room.h.

◆ rooms_sprite_pointer

int yaze::zelda3::rooms_sprite_pointer = 0x4C298

constexpr

Definition at line 42 of file room.h.

Referenced by yaze::zelda3::Room::LoadSprites().

◆ kRoomHeaderPointer

int yaze::zelda3::kRoomHeaderPointer = 0xB5DD

constexpr

Definition at line 43 of file room.h.

Referenced by yaze::zelda3::Room::LoadHeader(), and yaze::zelda3::Room::LoadRoomFromROM().

◆ kRoomHeaderPointerBank

int yaze::zelda3::kRoomHeaderPointerBank = 0xB5E7

constexpr

Definition at line 44 of file room.h.

Referenced by yaze::zelda3::Room::LoadHeader(), and yaze::zelda3::Room::LoadRoomFromROM().

◆ gfx_groups_pointer

int yaze::zelda3::gfx_groups_pointer = 0x6237

constexpr

Definition at line 45 of file room.h.

◆ chests_length_pointer

int yaze::zelda3::chests_length_pointer = 0xEBF6

constexpr

Definition at line 46 of file room.h.

Referenced by yaze::zelda3::Room::LoadChests().

◆ chests_data_pointer1

int yaze::zelda3::chests_data_pointer1 = 0xEBFB

constexpr

Definition at line 47 of file room.h.

Referenced by yaze::zelda3::Room::LoadChests().

◆ messages_id_dungeon

int yaze::zelda3::messages_id_dungeon = 0x3F61D

constexpr

Definition at line 49 of file room.h.

Referenced by yaze::zelda3::Room::LoadRoomFromROM().

◆ blocks_length

int yaze::zelda3::blocks_length = 0x8896

constexpr

Definition at line 51 of file room.h.

◆ blocks_pointer1

int yaze::zelda3::blocks_pointer1 = 0x15AFA

constexpr

Definition at line 52 of file room.h.

◆ blocks_pointer2

int yaze::zelda3::blocks_pointer2 = 0x15B01

constexpr

Definition at line 53 of file room.h.

◆ blocks_pointer3

int yaze::zelda3::blocks_pointer3 = 0x15B08

constexpr

Definition at line 54 of file room.h.

◆ blocks_pointer4

int yaze::zelda3::blocks_pointer4 = 0x15B0F

constexpr

Definition at line 55 of file room.h.

◆ torch_data

int yaze::zelda3::torch_data = 0x2736A

constexpr

Definition at line 56 of file room.h.

◆ torches_length_pointer

int yaze::zelda3::torches_length_pointer = 0x88C1

constexpr

Definition at line 57 of file room.h.

◆ sprite_blockset_pointer

int yaze::zelda3::sprite_blockset_pointer = 0x5B57

constexpr

Definition at line 58 of file room.h.

◆ sprites_data

int yaze::zelda3::sprites_data = 0x4D8B0

constexpr

Definition at line 60 of file room.h.

◆ sprites_data_empty_room

int yaze::zelda3::sprites_data_empty_room = 0x4D8AE

constexpr

Definition at line 61 of file room.h.

◆ sprites_end_data

int yaze::zelda3::sprites_end_data = 0x4EC9E

constexpr

Definition at line 62 of file room.h.

◆ pit_pointer

int yaze::zelda3::pit_pointer = 0x394AB

constexpr

Definition at line 63 of file room.h.

◆ pit_count

int yaze::zelda3::pit_count = 0x394A6

constexpr

Definition at line 64 of file room.h.

◆ doorPointers

int yaze::zelda3::doorPointers = 0xF83C0

constexpr

Definition at line 65 of file room.h.

◆ door_gfx_up

int yaze::zelda3::door_gfx_up = 0x4D9E

constexpr

Definition at line 68 of file room.h.

◆ door_gfx_down

int yaze::zelda3::door_gfx_down = 0x4E06

constexpr

Definition at line 69 of file room.h.

◆ door_gfx_cavexit_down

int yaze::zelda3::door_gfx_cavexit_down = 0x4E06

constexpr

Definition at line 70 of file room.h.

◆ door_gfx_left

int yaze::zelda3::door_gfx_left = 0x4E66

constexpr

Definition at line 71 of file room.h.

◆ door_gfx_right

int yaze::zelda3::door_gfx_right = 0x4EC6

constexpr

Definition at line 72 of file room.h.

◆ door_pos_up

int yaze::zelda3::door_pos_up = 0x197E

constexpr

Definition at line 73 of file room.h.

◆ door_pos_down

int yaze::zelda3::door_pos_down = 0x1996

constexpr

Definition at line 74 of file room.h.

◆ door_pos_left

int yaze::zelda3::door_pos_left = 0x19AE

constexpr

Definition at line 75 of file room.h.

◆ door_pos_right

int yaze::zelda3::door_pos_right = 0x19C6

constexpr

Definition at line 76 of file room.h.

◆ dungeon_spr_ptrs

int yaze::zelda3::dungeon_spr_ptrs = 0x090000

constexpr

Definition at line 78 of file room.h.

◆ NumberOfRooms

int yaze::zelda3::NumberOfRooms = 296

constexpr

Definition at line 80 of file room.h.

◆ stairsObjects

uint16_t yaze::zelda3::stairsObjects[] = {0x139, 0x138, 0x13B, 0x12E, 0x12D}

constexpr

Definition at line 82 of file room.h.

Referenced by yaze::zelda3::Room::LoadObjects().

◆ kRoomNames

std::string_view yaze::zelda3::kRoomNames[]

constexpr

Definition at line 202 of file room.h.

Referenced by yaze::editor::DungeonEditor::DrawDungeonTabView(), and yaze::editor::DungeonEditor::DrawRoomSelector().

◆ kEntranceRoom

int yaze::zelda3::kEntranceRoom = 0x14813

constexpr

Definition at line 12 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance().

◆ kEntranceScrollEdge

int yaze::zelda3::kEntranceScrollEdge = 0x1491D

constexpr

Definition at line 15 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceYScroll

int yaze::zelda3::kEntranceYScroll = 0x14D45

constexpr

Definition at line 16 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceXScroll

int yaze::zelda3::kEntranceXScroll = 0x14E4F

constexpr

Definition at line 17 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceYPosition

int yaze::zelda3::kEntranceYPosition = 0x14F59

constexpr

Definition at line 18 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceXPosition

int yaze::zelda3::kEntranceXPosition = 0x15063

constexpr

Definition at line 19 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceCameraYTrigger

int yaze::zelda3::kEntranceCameraYTrigger = 0x1516D

constexpr

Definition at line 20 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceCameraXTrigger

int yaze::zelda3::kEntranceCameraXTrigger = 0x15277

constexpr

Definition at line 21 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceBlockset

int yaze::zelda3::kEntranceBlockset = 0x15381

constexpr

Definition at line 23 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceFloor

int yaze::zelda3::kEntranceFloor = 0x15406

constexpr

Definition at line 24 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceDungeon

int yaze::zelda3::kEntranceDungeon = 0x1548B

constexpr

Definition at line 25 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceDoor

int yaze::zelda3::kEntranceDoor = 0x15510

constexpr

Definition at line 26 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceLadderBG

int yaze::zelda3::kEntranceLadderBG = 0x15595

constexpr

Definition at line 29 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntrancescrolling

int yaze::zelda3::kEntrancescrolling = 0x1561A

constexpr

Definition at line 30 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceScrollQuadrant

int yaze::zelda3::kEntranceScrollQuadrant = 0x1569F

constexpr

Definition at line 31 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceExit

int yaze::zelda3::kEntranceExit = 0x15724

constexpr

Definition at line 32 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kEntranceMusic

int yaze::zelda3::kEntranceMusic = 0x1582E

constexpr

Definition at line 33 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceroom

int yaze::zelda3::kStartingEntranceroom = 0x15B6E

constexpr

Definition at line 36 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceScrollEdge

int yaze::zelda3::kStartingEntranceScrollEdge = 0x15B7C

constexpr

Definition at line 39 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceYScroll

int yaze::zelda3::kStartingEntranceYScroll = 0x15BB4

constexpr

Definition at line 40 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceXScroll

int yaze::zelda3::kStartingEntranceXScroll = 0x15BC2

constexpr

Definition at line 41 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceYPosition

int yaze::zelda3::kStartingEntranceYPosition = 0x15BD0

constexpr

Definition at line 42 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceXPosition

int yaze::zelda3::kStartingEntranceXPosition = 0x15BDE

constexpr

Definition at line 43 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceCameraYTrigger

int yaze::zelda3::kStartingEntranceCameraYTrigger = 0x15BEC

constexpr

Definition at line 44 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceCameraXTrigger

int yaze::zelda3::kStartingEntranceCameraXTrigger = 0x15BFA

constexpr

Definition at line 45 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceBlockset

int yaze::zelda3::kStartingEntranceBlockset = 0x15C08

constexpr

Definition at line 47 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceFloor

int yaze::zelda3::kStartingEntranceFloor = 0x15C0F

constexpr

Definition at line 48 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceDungeon

int yaze::zelda3::kStartingEntranceDungeon = 0x15C16

constexpr

Definition at line 49 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceDoor

int yaze::zelda3::kStartingEntranceDoor = 0x15C2B

constexpr

Definition at line 51 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceLadderBG

int yaze::zelda3::kStartingEntranceLadderBG = 0x15C1D

constexpr

Definition at line 54 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntrancescrolling

int yaze::zelda3::kStartingEntrancescrolling = 0x15C24

constexpr

Definition at line 56 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceScrollQuadrant

int yaze::zelda3::kStartingEntranceScrollQuadrant = 0x15C2B

constexpr

Definition at line 57 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceexit

int yaze::zelda3::kStartingEntranceexit = 0x15C32

constexpr

Definition at line 58 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntrancemusic

int yaze::zelda3::kStartingEntrancemusic = 0x15C4E

constexpr

Definition at line 59 of file room_entrance.h.

Referenced by yaze::zelda3::RoomEntrance::RoomEntrance(), and yaze::zelda3::RoomEntrance::Save().

◆ kStartingEntranceentrance

int yaze::zelda3::kStartingEntranceentrance = 0x15C40

constexpr

Definition at line 60 of file room_entrance.h.

◆ items_data_start

int yaze::zelda3::items_data_start = 0xDDE9

constexpr

Definition at line 62 of file room_entrance.h.

◆ items_data_end

int yaze::zelda3::items_data_end = 0xE6B2

constexpr

Definition at line 63 of file room_entrance.h.

◆ initial_equipement

int yaze::zelda3::initial_equipement = 0x271A6

constexpr

Definition at line 64 of file room_entrance.h.

◆ chests_backupitems

int yaze::zelda3::chests_backupitems = 0x3B528

constexpr

Definition at line 67 of file room_entrance.h.

◆ chests_yoffset

int yaze::zelda3::chests_yoffset = 0x4836C

constexpr

Definition at line 68 of file room_entrance.h.

◆ chests_xoffset

int yaze::zelda3::chests_xoffset = 0x4836C + (76 * 1)

constexpr

Definition at line 69 of file room_entrance.h.

◆ chests_itemsgfx

int yaze::zelda3::chests_itemsgfx = 0x4836C + (76 * 2)

constexpr

Definition at line 70 of file room_entrance.h.

◆ chests_itemswide

int yaze::zelda3::chests_itemswide = 0x4836C + (76 * 3)

constexpr

Definition at line 71 of file room_entrance.h.

◆ chests_itemsproperties

int yaze::zelda3::chests_itemsproperties = 0x4836C + (76 * 4)

constexpr

Definition at line 72 of file room_entrance.h.

◆ chests_sramaddress

int yaze::zelda3::chests_sramaddress = 0x4836C + (76 * 5)

constexpr

Definition at line 73 of file room_entrance.h.

◆ chests_sramvalue

int yaze::zelda3::chests_sramvalue = 0x4836C + (76 * 7)

constexpr

Definition at line 74 of file room_entrance.h.

◆ chests_msgid

int yaze::zelda3::chests_msgid = 0x442DD

constexpr

Definition at line 75 of file room_entrance.h.

◆ dungeons_startrooms

int yaze::zelda3::dungeons_startrooms = 0x7939

constexpr

Definition at line 77 of file room_entrance.h.

◆ dungeons_endrooms

int yaze::zelda3::dungeons_endrooms = 0x792D

constexpr

Definition at line 78 of file room_entrance.h.

◆ dungeons_bossrooms

int yaze::zelda3::dungeons_bossrooms = 0x10954

constexpr

Definition at line 79 of file room_entrance.h.

◆ bedPositionX

int yaze::zelda3::bedPositionX = 0x039A37

constexpr

Definition at line 82 of file room_entrance.h.

◆ bedPositionY

int yaze::zelda3::bedPositionY = 0x039A32

constexpr

Definition at line 83 of file room_entrance.h.

◆ bedPositionResetXLow

int yaze::zelda3::bedPositionResetXLow = 0x02DE53

constexpr

Definition at line 86 of file room_entrance.h.

◆ bedPositionResetXHigh

int yaze::zelda3::bedPositionResetXHigh = 0x02DE58

constexpr

Definition at line 87 of file room_entrance.h.

◆ bedPositionResetYLow

int yaze::zelda3::bedPositionResetYLow = 0x02DE5D

constexpr

Definition at line 90 of file room_entrance.h.

◆ bedPositionResetYHigh

int yaze::zelda3::bedPositionResetYHigh = 0x02DE62

constexpr

Definition at line 91 of file room_entrance.h.

◆ bedSheetPositionX

int yaze::zelda3::bedSheetPositionX = 0x0480BD

constexpr

Definition at line 93 of file room_entrance.h.

◆ bedSheetPositionY

int yaze::zelda3::bedSheetPositionY = 0x0480B8

constexpr

Definition at line 94 of file room_entrance.h.

◆ kRoomObjectSubtype1

int yaze::zelda3::kRoomObjectSubtype1 = 0x8000

constexpr

Definition at line 50 of file room_object.h.

Referenced by FetchSubtypeInfo(), and yaze::zelda3::Subtype1::Subtype1().

◆ kRoomObjectSubtype2

int yaze::zelda3::kRoomObjectSubtype2 = 0x83F0

constexpr

Definition at line 51 of file room_object.h.

Referenced by FetchSubtypeInfo(), and yaze::zelda3::Subtype2::Subtype2().

◆ kRoomObjectSubtype3

int yaze::zelda3::kRoomObjectSubtype3 = 0x84F0

constexpr

Definition at line 52 of file room_object.h.

Referenced by FetchSubtypeInfo(), and yaze::zelda3::Subtype3::Subtype3().

◆ kRoomObjectTileAddress

int yaze::zelda3::kRoomObjectTileAddress = 0x1B52

constexpr

Definition at line 53 of file room_object.h.

Referenced by yaze::zelda3::Subtype1::Subtype1(), yaze::zelda3::Subtype2::Subtype2(), and yaze::zelda3::Subtype3::Subtype3().

◆ kRoomObjectTileAddressFloor

int yaze::zelda3::kRoomObjectTileAddressFloor = 0x1B5A

constexpr

Definition at line 54 of file room_object.h.

◆ kMap32TilesLength

int yaze::zelda3::kMap32TilesLength = 0x33F0

constexpr

Definition at line 108 of file overworld.cc.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles().

◆ GravesYTilePos

int yaze::zelda3::GravesYTilePos = 0x49968

constexpr

Definition at line 20 of file overworld.h.

◆ GravesXTilePos

int yaze::zelda3::GravesXTilePos = 0x49986

constexpr

Definition at line 21 of file overworld.h.

◆ GravesTilemapPos

int yaze::zelda3::GravesTilemapPos = 0x499A4

constexpr

Definition at line 22 of file overworld.h.

◆ GravesGFX

int yaze::zelda3::GravesGFX = 0x499C2

constexpr

Definition at line 23 of file overworld.h.

◆ GravesXPos

int yaze::zelda3::GravesXPos = 0x4994A

constexpr

Definition at line 24 of file overworld.h.

◆ GravesYLine

int yaze::zelda3::GravesYLine = 0x4993A

constexpr

Definition at line 25 of file overworld.h.

◆ GravesCountOnY

int yaze::zelda3::GravesCountOnY = 0x499E0

constexpr

Definition at line 26 of file overworld.h.

◆ GraveLinkSpecialHole

int yaze::zelda3::GraveLinkSpecialHole = 0x46DD9

constexpr

Definition at line 27 of file overworld.h.

◆ GraveLinkSpecialStairs

int yaze::zelda3::GraveLinkSpecialStairs = 0x46DE0

constexpr

Definition at line 28 of file overworld.h.

◆ kOverworldMapPaletteIds

int yaze::zelda3::kOverworldMapPaletteIds = 0x7D1C

constexpr

Definition at line 30 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::BuildMap(), yaze::zelda3::OverworldMap::LoadAreaInfo(), yaze::zelda3::OverworldMap::LoadPalette(), and yaze::zelda3::Overworld::SaveMapProperties().

◆ kOverworldSpritePaletteIds

int yaze::zelda3::kOverworldSpritePaletteIds = 0x7B41

constexpr

Definition at line 31 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo(), yaze::zelda3::OverworldMap::LoadPalette(), and yaze::zelda3::Overworld::SaveMapProperties().

◆ kOverworldSpritePaletteGroup

int yaze::zelda3::kOverworldSpritePaletteGroup = 0x75580

constexpr

Definition at line 32 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadPalette().

◆ kOverworldSpriteset

int yaze::zelda3::kOverworldSpriteset = 0x7A41

constexpr

Definition at line 33 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo(), and yaze::zelda3::Overworld::SaveMapProperties().

◆ kOverworldSpecialGfxGroup

int yaze::zelda3::kOverworldSpecialGfxGroup = 0x16821

constexpr

Definition at line 34 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::BuildMap(), and yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldSpecialPalGroup

int yaze::zelda3::kOverworldSpecialPalGroup = 0x16831

constexpr

Definition at line 35 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::BuildMap(), and yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldSpritesBeginning

int yaze::zelda3::kOverworldSpritesBeginning = 0x4C881

constexpr

Definition at line 36 of file overworld.h.

Referenced by yaze::zelda3::Overworld::LoadSprites().

◆ kOverworldSpritesAgahnim

int yaze::zelda3::kOverworldSpritesAgahnim = 0x4CA21

constexpr

Definition at line 37 of file overworld.h.

Referenced by yaze::zelda3::Overworld::LoadSprites().

◆ kOverworldSpritesZelda

int yaze::zelda3::kOverworldSpritesZelda = 0x4C901

constexpr

Definition at line 38 of file overworld.h.

Referenced by yaze::zelda3::Overworld::LoadSprites().

◆ kAreaGfxIdPtr

int yaze::zelda3::kAreaGfxIdPtr = 0x7C9C

constexpr

Definition at line 40 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::BuildMap(), yaze::zelda3::OverworldMap::LoadAreaInfo(), and yaze::zelda3::Overworld::SaveMapProperties().

◆ kOverworldMessageIds

int yaze::zelda3::kOverworldMessageIds = 0x3F51D

constexpr

Definition at line 41 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldMusicBeginning

int yaze::zelda3::kOverworldMusicBeginning = 0x14303

constexpr

Definition at line 43 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldMusicZelda

int yaze::zelda3::kOverworldMusicZelda = 0x14303 + 0x40

constexpr

Definition at line 44 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldMusicMasterSword

int yaze::zelda3::kOverworldMusicMasterSword = 0x14303 + 0x80

constexpr

Definition at line 45 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldMusicAgahnim

int yaze::zelda3::kOverworldMusicAgahnim = 0x14303 + 0xC0

constexpr

Definition at line 46 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldMusicDarkWorld

int yaze::zelda3::kOverworldMusicDarkWorld = 0x14403

constexpr

Definition at line 47 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo().

◆ kOverworldEntranceAllowedTilesLeft

int yaze::zelda3::kOverworldEntranceAllowedTilesLeft = 0xDB8C1

constexpr

Definition at line 48 of file overworld.h.

◆ kOverworldEntranceAllowedTilesRight

int yaze::zelda3::kOverworldEntranceAllowedTilesRight = 0xDB917

constexpr

Definition at line 49 of file overworld.h.

◆ kOverworldMapSize

int yaze::zelda3::kOverworldMapSize = 0x12844

constexpr

Definition at line 52 of file overworld.h.

Referenced by yaze::zelda3::OverworldMap::LoadAreaInfo(), and yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldMapSizeHighByte

int yaze::zelda3::kOverworldMapSizeHighByte = 0x12884

constexpr

Definition at line 55 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldMapParentId

int yaze::zelda3::kOverworldMapParentId = 0x125EC

constexpr

Definition at line 63 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldTransitionPositionY

int yaze::zelda3::kOverworldTransitionPositionY = 0x128C4

constexpr

Definition at line 64 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldTransitionPositionX

int yaze::zelda3::kOverworldTransitionPositionX = 0x12944

constexpr

Definition at line 65 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenSize

int yaze::zelda3::kOverworldScreenSize = 0x1788D

constexpr

Definition at line 66 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenSizeForLoading

int yaze::zelda3::kOverworldScreenSizeForLoading = 0x4C635

constexpr

Definition at line 67 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenTileMapChangeByScreen1

int yaze::zelda3::kOverworldScreenTileMapChangeByScreen1 = 0x12634

constexpr

Definition at line 69 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenTileMapChangeByScreen2

int yaze::zelda3::kOverworldScreenTileMapChangeByScreen2 = 0x126B4

constexpr

Definition at line 70 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenTileMapChangeByScreen3

int yaze::zelda3::kOverworldScreenTileMapChangeByScreen3 = 0x12734

constexpr

Definition at line 71 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldScreenTileMapChangeByScreen4

int yaze::zelda3::kOverworldScreenTileMapChangeByScreen4 = 0x127B4

constexpr

Definition at line 72 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kOverworldMapDataOverflow

int yaze::zelda3::kOverworldMapDataOverflow = 0x130000

constexpr

Definition at line 74 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveOverworldMaps().

◆ kTransitionTargetNorth

int yaze::zelda3::kTransitionTargetNorth = 0x13EE2

constexpr

Definition at line 76 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ kTransitionTargetWest

int yaze::zelda3::kTransitionTargetWest = 0x13F62

constexpr

Definition at line 77 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveLargeMaps().

◆ overworldCustomMosaicASM

int yaze::zelda3::overworldCustomMosaicASM = 0x1301D0

constexpr

Definition at line 78 of file overworld.h.

◆ overworldCustomMosaicArray

int yaze::zelda3::overworldCustomMosaicArray = 0x1301F0

constexpr

Definition at line 79 of file overworld.h.

◆ kMap16TilesExpanded

int yaze::zelda3::kMap16TilesExpanded = 0x1E8000

constexpr

Definition at line 82 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap16Tiles(), and yaze::zelda3::Overworld::SaveMap16Expanded().

◆ kMap32TileTRExpanded

int yaze::zelda3::kMap32TileTRExpanded = 0x020000

constexpr

Definition at line 83 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles(), and yaze::zelda3::Overworld::SaveMap32Expanded().

◆ kMap32TileBLExpanded

int yaze::zelda3::kMap32TileBLExpanded = 0x1F0000

constexpr

Definition at line 84 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles(), and yaze::zelda3::Overworld::SaveMap32Expanded().

◆ kMap32TileBRExpanded

int yaze::zelda3::kMap32TileBRExpanded = 0x1F8000

constexpr

Definition at line 85 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles(), and yaze::zelda3::Overworld::SaveMap32Expanded().

◆ kMap32TileCountExpanded

int yaze::zelda3::kMap32TileCountExpanded = 0x0067E0

constexpr

Definition at line 86 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles().

◆ kMap32ExpandedFlagPos

int yaze::zelda3::kMap32ExpandedFlagPos = 0x01772E

constexpr

Definition at line 87 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap32Tiles().

◆ kMap16ExpandedFlagPos

int yaze::zelda3::kMap16ExpandedFlagPos = 0x02FD28

constexpr

Definition at line 88 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap16Tiles().

◆ kOverworldEntranceExpandedFlagPos

int yaze::zelda3::kOverworldEntranceExpandedFlagPos = 0x0DB895

constexpr

Definition at line 89 of file overworld.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances().

◆ kOverworldCompressedMapPos

int yaze::zelda3::kOverworldCompressedMapPos = 0x058000

constexpr

Definition at line 91 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveOverworldMaps().

◆ kOverworldCompressedOverflowPos

int yaze::zelda3::kOverworldCompressedOverflowPos = 0x137FFF

constexpr

Definition at line 92 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveOverworldMaps().

◆ kNumTileTypes

int yaze::zelda3::kNumTileTypes = 0x200

constexpr

Definition at line 94 of file overworld.h.

Referenced by yaze::zelda3::Overworld::LoadTileTypes().

◆ kMap16Tiles

int yaze::zelda3::kMap16Tiles = 0x78000

constexpr

Definition at line 95 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap16Tiles(), and yaze::zelda3::Overworld::SaveMap16Tiles().

◆ kNumOverworldMaps

int yaze::zelda3::kNumOverworldMaps = 160

constexpr

Definition at line 96 of file overworld.h.

Referenced by yaze::zelda3::Overworld::DecompressAllMapTiles(), yaze::zelda3::anonymous_namespace{overworld.cc}::GetAllTile16(), yaze::zelda3::Overworld::Load(), yaze::editor::OverworldEditor::LoadGraphics(), yaze::zelda3::Overworld::LoadOverworldMaps(), yaze::zelda3::OverworldMap::LoadPalette(), and yaze::zelda3::Overworld::SaveOverworldMaps().

◆ kNumTile16Individual

int yaze::zelda3::kNumTile16Individual = 4096

constexpr

Definition at line 97 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap16Tiles(), yaze::editor::OverworldEditor::LoadGraphics(), and yaze::editor::OverworldEditor::RefreshTile16Blockset().

◆ Map32PerScreen

int yaze::zelda3::Map32PerScreen = 256

constexpr

Definition at line 98 of file overworld.h.

◆ NumberOfMap16

int yaze::zelda3::NumberOfMap16 = 3752

constexpr

Definition at line 99 of file overworld.h.

Referenced by yaze::zelda3::Overworld::SaveMap16Tiles().

◆ NumberOfMap16Ex

int yaze::zelda3::NumberOfMap16Ex = 4096

constexpr

Definition at line 100 of file overworld.h.

Referenced by yaze::zelda3::Overworld::AssembleMap16Tiles().

◆ LimitOfMap32

int yaze::zelda3::LimitOfMap32 = 8864

constexpr

Definition at line 101 of file overworld.h.

Referenced by yaze::zelda3::Overworld::CreateTile32Tilemap().

◆ NumberOfOWSprites

int yaze::zelda3::NumberOfOWSprites = 352

constexpr

Definition at line 102 of file overworld.h.

◆ NumberOfMap32

int yaze::zelda3::NumberOfMap32 = Map32PerScreen * kNumOverworldMaps

constexpr

Definition at line 103 of file overworld.h.

Referenced by yaze::zelda3::Overworld::CreateTile32Tilemap().

◆ kNumOverworldEntrances

int yaze::zelda3::kNumOverworldEntrances = 129

constexpr

Definition at line 13 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::SaveEntrances().

◆ kNumOverworldHoles

int yaze::zelda3::kNumOverworldHoles = 0x13

constexpr

Definition at line 14 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntranceMap

int yaze::zelda3::kOverworldEntranceMap = 0xDB96F

constexpr

Definition at line 16 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntrancePos

int yaze::zelda3::kOverworldEntrancePos = 0xDBA71

constexpr

Definition at line 17 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntranceEntranceId

int yaze::zelda3::kOverworldEntranceEntranceId = 0xDBB73

constexpr

Definition at line 18 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntranceMapExpanded

int yaze::zelda3::kOverworldEntranceMapExpanded = 0x0DB55F

constexpr

Definition at line 20 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntrancePosExpanded

int yaze::zelda3::kOverworldEntrancePosExpanded = 0x0DB35F

constexpr

Definition at line 21 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldEntranceEntranceIdExpanded

int yaze::zelda3::kOverworldEntranceEntranceIdExpanded = 0x0DB75F

constexpr

Definition at line 22 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadEntrances(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldHolePos

int yaze::zelda3::kOverworldHolePos = 0xDB800

constexpr

Definition at line 26 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadHoles(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldHoleArea

int yaze::zelda3::kOverworldHoleArea = 0xDB826

constexpr

Definition at line 30 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadHoles(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kOverworldHoleEntrance

int yaze::zelda3::kOverworldHoleEntrance = 0xDB84C

constexpr

Definition at line 33 of file overworld_entrance.h.

Referenced by yaze::zelda3::Overworld::LoadHoles(), and yaze::zelda3::Overworld::SaveEntrances().

◆ kEntranceTileTypePtrLow

int yaze::zelda3::kEntranceTileTypePtrLow = 0xDB8BF

constexpr

Definition at line 90 of file overworld_entrance.h.

Referenced by LoadEntranceTileTypes().

◆ kEntranceTileTypePtrHigh

int yaze::zelda3::kEntranceTileTypePtrHigh = 0xDB917

constexpr

Definition at line 91 of file overworld_entrance.h.

Referenced by LoadEntranceTileTypes().

◆ kNumEntranceTileTypes

int yaze::zelda3::kNumEntranceTileTypes = 0x2C

constexpr

Definition at line 92 of file overworld_entrance.h.

Referenced by LoadEntranceTileTypes().

◆ kNumOverworldExits

int yaze::zelda3::kNumOverworldExits = 0x4F

constexpr

Definition at line 13 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::SaveExits().

◆ OWExitRoomId

int yaze::zelda3::OWExitRoomId = 0x15D8A

constexpr

Definition at line 14 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitMapId

int yaze::zelda3::OWExitMapId = 0x15E28

constexpr

Definition at line 17 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitVram

int yaze::zelda3::OWExitVram = 0x15E77

constexpr

Definition at line 18 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitYScroll

int yaze::zelda3::OWExitYScroll = 0x15F15

constexpr

Definition at line 19 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitXScroll

int yaze::zelda3::OWExitXScroll = 0x15FB3

constexpr

Definition at line 20 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitYPlayer

int yaze::zelda3::OWExitYPlayer = 0x16051

constexpr

Definition at line 21 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitXPlayer

int yaze::zelda3::OWExitXPlayer = 0x160EF

constexpr

Definition at line 22 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitYCamera

int yaze::zelda3::OWExitYCamera = 0x1618D

constexpr

Definition at line 23 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitXCamera

int yaze::zelda3::OWExitXCamera = 0x1622B

constexpr

Definition at line 24 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitDoorPosition

int yaze::zelda3::OWExitDoorPosition = 0x15724

constexpr

Definition at line 25 of file overworld_exit.h.

◆ OWExitUnk1

int yaze::zelda3::OWExitUnk1 = 0x162C9

constexpr

Definition at line 26 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitUnk2

int yaze::zelda3::OWExitUnk2 = 0x16318

constexpr

Definition at line 27 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitDoorType1

int yaze::zelda3::OWExitDoorType1 = 0x16367

constexpr

Definition at line 28 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitDoorType2

int yaze::zelda3::OWExitDoorType2 = 0x16405

constexpr

Definition at line 29 of file overworld_exit.h.

Referenced by yaze::zelda3::Overworld::LoadExits(), and yaze::zelda3::Overworld::SaveExits().

◆ OWExitMapIdWhirlpool

int yaze::zelda3::OWExitMapIdWhirlpool = 0x16AE5

constexpr

Definition at line 31 of file overworld_exit.h.

◆ OWExitVramWhirlpool

int yaze::zelda3::OWExitVramWhirlpool = 0x16B07

constexpr

Definition at line 32 of file overworld_exit.h.

◆ OWExitYScrollWhirlpool

int yaze::zelda3::OWExitYScrollWhirlpool = 0x16B29

constexpr

Definition at line 33 of file overworld_exit.h.

◆ OWExitXScrollWhirlpool

int yaze::zelda3::OWExitXScrollWhirlpool = 0x16B4B

constexpr

Definition at line 34 of file overworld_exit.h.

◆ OWExitYPlayerWhirlpool

int yaze::zelda3::OWExitYPlayerWhirlpool = 0x16B6D

constexpr

Definition at line 35 of file overworld_exit.h.

◆ OWExitXPlayerWhirlpool

int yaze::zelda3::OWExitXPlayerWhirlpool = 0x16B8F

constexpr

Definition at line 36 of file overworld_exit.h.

◆ OWExitYCameraWhirlpool

int yaze::zelda3::OWExitYCameraWhirlpool = 0x16BB1

constexpr

Definition at line 37 of file overworld_exit.h.

◆ OWExitXCameraWhirlpool

int yaze::zelda3::OWExitXCameraWhirlpool = 0x16BD3

constexpr

Definition at line 38 of file overworld_exit.h.

◆ OWExitUnk1Whirlpool

int yaze::zelda3::OWExitUnk1Whirlpool = 0x16BF5

constexpr

Definition at line 39 of file overworld_exit.h.

◆ OWExitUnk2Whirlpool

int yaze::zelda3::OWExitUnk2Whirlpool = 0x16C17

constexpr

Definition at line 40 of file overworld_exit.h.

◆ OWWhirlpoolPosition

int yaze::zelda3::OWWhirlpoolPosition = 0x16CF8

constexpr

Definition at line 41 of file overworld_exit.h.

◆ kNumOverworldMapItemPointers

int yaze::zelda3::kNumOverworldMapItemPointers = 0x80

constexpr

Definition at line 15 of file overworld_item.h.

Referenced by yaze::zelda3::Overworld::SaveItems().

◆ kOverworldItemsPointers

int yaze::zelda3::kOverworldItemsPointers = 0xDC2F9

constexpr

Definition at line 16 of file overworld_item.h.

Referenced by yaze::zelda3::Overworld::SaveItems().

◆ kOverworldItemsAddress

int yaze::zelda3::kOverworldItemsAddress = 0xDC8B9

constexpr

Definition at line 17 of file overworld_item.h.

Referenced by yaze::zelda3::Overworld::LoadItems().

◆ kOverworldItemsBank

int yaze::zelda3::kOverworldItemsBank = 0xDC8BF

constexpr

Definition at line 18 of file overworld_item.h.

◆ kOverworldItemsEndData

int yaze::zelda3::kOverworldItemsEndData = 0xDC89C

constexpr

Definition at line 19 of file overworld_item.h.

Referenced by yaze::zelda3::Overworld::SaveItems().

◆ kSecretItemNames

const std::vector<std::string> yaze::zelda3::kSecretItemNames

Initial value:

= {
    "Nothing",
    "Green Rupee",
    "Rock hoarder",
    "Bee",
    "Health pack",
    "Bomb",
    "Heart ",
    "Blue Rupee",
    "Key",
    "Arrow",
    "Bomb",
    "Heart",
    "Magic",
    "Full Magic",
    "Cucco",
    "Green Soldier",
    "Bush Stal",
    "Blue Soldier",
    "Landmine",
    "Heart",
    "Fairy",
    "Heart",
    "Nothing ",
    "Hole",
    "Warp",
    "Staircase",
    "Bombable",
    "Switch"
}

Definition at line 68 of file overworld_item.h.

Referenced by yaze::editor::DrawItemEditorPopup(), yaze::editor::DrawItemInsertPopup(), and yaze::editor::OverworldEditor::DrawOverworldItems().

◆ OverworldCustomASMHasBeenApplied

int yaze::zelda3::OverworldCustomASMHasBeenApplied = 0x140145

constexpr

Definition at line 20 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::OverworldMap().

◆ OverworldCustomAreaSpecificBGPalette

int yaze::zelda3::OverworldCustomAreaSpecificBGPalette = 0x140000

constexpr

Definition at line 23 of file overworld_map.h.

◆ OverworldCustomAreaSpecificBGEnabled

int yaze::zelda3::OverworldCustomAreaSpecificBGEnabled = 0x140140

constexpr

Definition at line 26 of file overworld_map.h.

◆ OverworldCustomMainPaletteArray

int yaze::zelda3::OverworldCustomMainPaletteArray = 0x140160

constexpr

Definition at line 29 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ OverworldCustomMainPaletteEnabled

int yaze::zelda3::OverworldCustomMainPaletteEnabled = 0x140141

constexpr

Definition at line 31 of file overworld_map.h.

◆ OverworldCustomMosaicArray

int yaze::zelda3::OverworldCustomMosaicArray = 0x140200

constexpr

Definition at line 34 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ OverworldCustomMosaicEnabled

int yaze::zelda3::OverworldCustomMosaicEnabled = 0x140142

constexpr

Definition at line 37 of file overworld_map.h.

◆ OverworldCustomAnimatedGFXArray

int yaze::zelda3::OverworldCustomAnimatedGFXArray = 0x1402A0

constexpr

Definition at line 40 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ OverworldCustomAnimatedGFXEnabled

int yaze::zelda3::OverworldCustomAnimatedGFXEnabled = 0x140143

constexpr

Definition at line 43 of file overworld_map.h.

◆ OverworldCustomSubscreenOverlayArray

int yaze::zelda3::OverworldCustomSubscreenOverlayArray = 0x140340

constexpr

Definition at line 46 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ OverworldCustomSubscreenOverlayEnabled

int yaze::zelda3::OverworldCustomSubscreenOverlayEnabled = 0x140144

constexpr

Definition at line 49 of file overworld_map.h.

◆ OverworldCustomTileGFXGroupArray

int yaze::zelda3::OverworldCustomTileGFXGroupArray = 0x140480

constexpr

Definition at line 52 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ OverworldCustomTileGFXGroupEnabled

int yaze::zelda3::OverworldCustomTileGFXGroupEnabled = 0x140148

constexpr

Definition at line 55 of file overworld_map.h.

◆ kDarkWorldMapIdStart

int yaze::zelda3::kDarkWorldMapIdStart = 0x40

constexpr

Definition at line 57 of file overworld_map.h.

◆ kSpecialWorldMapIdStart

int yaze::zelda3::kSpecialWorldMapIdStart = 0x80

constexpr

Definition at line 58 of file overworld_map.h.

Referenced by yaze::zelda3::OverworldMap::BuildMap(), yaze::zelda3::OverworldMap::LoadAreaInfo(), yaze::zelda3::OverworldMap::LoadCustomOverworldData(), yaze::zelda3::OverworldMap::LoadMainBlocksetId(), yaze::zelda3::Overworld::LoadOverworldMaps(), yaze::zelda3::OverworldMap::LoadPalette(), yaze::zelda3::Overworld::SaveLargeMaps(), yaze::zelda3::Overworld::SaveMapProperties(), and yaze::zelda3::OverworldMap::SetupCustomTileset().

◆ kDungeonMapRoomsPtr

int yaze::zelda3::kDungeonMapRoomsPtr = 0x57605

constexpr

Definition at line 14 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMaps(), and yaze::editor::ScreenEditor::SaveDungeonMaps().

◆ kDungeonMapFloors

int yaze::zelda3::kDungeonMapFloors = 0x575D9

constexpr

Definition at line 15 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMaps().

◆ kDungeonMapGfxPtr

int yaze::zelda3::kDungeonMapGfxPtr = 0x57BE4

constexpr

Definition at line 17 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMaps(), and yaze::editor::ScreenEditor::SaveDungeonMaps().

◆ kDungeonMapDataStart

int yaze::zelda3::kDungeonMapDataStart = 0x57039

constexpr

Definition at line 20 of file dungeon_map.h.

◆ kDungeonMapExpCheck

int yaze::zelda3::kDungeonMapExpCheck = 0x56652

constexpr

Definition at line 23 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMapTile16(), and yaze::editor::ScreenEditor::SaveDungeonMapTile16().

◆ kDungeonMapTile16

int yaze::zelda3::kDungeonMapTile16 = 0x57009

constexpr

Definition at line 24 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMapTile16(), and yaze::editor::ScreenEditor::SaveDungeonMapTile16().

◆ kDungeonMapTile16Expanded

int yaze::zelda3::kDungeonMapTile16Expanded = 0x109010

constexpr

Definition at line 25 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMapTile16(), and yaze::editor::ScreenEditor::SaveDungeonMapTile16().

◆ kDungeonMapBossRooms

int yaze::zelda3::kDungeonMapBossRooms = 0x56807

constexpr

Definition at line 28 of file dungeon_map.h.

Referenced by yaze::editor::ScreenEditor::LoadDungeonMaps().

◆ kTriforceVertices

int yaze::zelda3::kTriforceVertices = 0x04FFD2

constexpr

Definition at line 29 of file dungeon_map.h.

◆ kTriforceFaces

int yaze::zelda3::kTriforceFaces = 0x04FFE4

constexpr

Definition at line 30 of file dungeon_map.h.

◆ kCrystalVertices

int yaze::zelda3::kCrystalVertices = 0x04FF98

constexpr

Definition at line 32 of file dungeon_map.h.

◆ kInventoryStart

int yaze::zelda3::kInventoryStart = 0x6564A

constexpr

Definition at line 13 of file inventory.h.

◆ kBowItemPos

int yaze::zelda3::kBowItemPos = 0x6F631

constexpr

Definition at line 14 of file inventory.h.

Referenced by yaze::zelda3::Inventory::Create().

◆ kSpriteProperties

const char* yaze::zelda3::kSpriteProperties[]

constexpr

Initial value:

= {"!SPRID",
                                             "!NbrTiles",
                                             "!Harmless",
                                             "!HVelocity",
                                             "!Health",
                                             "!Damage",
                                             "!DeathAnimation",
                                             "!ImperviousAll",
                                             "!SmallShadow",
                                             "!Shadow",
                                             "!Palette",
                                             "!Hitbox",
                                             "!Persist",
                                             "!Statis",
                                             "!CollisionLayer",
                                             "!CanFall",
                                             "!DeflectArrow",
                                             "!WaterSprite",
                                             "!Blockable",
                                             "!Prize",
                                             "!Sound",
                                             "!Interaction",
                                             "!Statue",
                                             "!DeflectProjectiles",
                                             "!ImperviousArrow",
                                             "!ImpervSwordHammer",
                                             "!Boss"}

Definition at line 64 of file sprite_builder.h.

Referenced by yaze::zelda3::SpriteBuilder::BuildProperties().

	yaze 0.2.2 Link to the Past ROM Editor

Namespaces

Classes

Typedefs

Enumerations

Functions

Variables

Detailed Description

Typedef Documentation

◆ OverworldBlockset

◆ OverworldMapTiles

Enumeration Type Documentation

◆ SpecialObjectType

◆ Sorting

◆ ObjectOption

◆ CollisionKey

◆ EffectKey

◆ TagKey

Function Documentation

◆ operator|()

◆ operator&()

◆ operator^()

◆ operator~()

◆ FetchSubtypeInfo()

◆ stle16b_i()

◆ stle16b()

◆ ldle16b()

◆ ldle16b_i()

◆ LoadEntranceTileTypes()

◆ LoadDungeonMapGfxFromBinary()

◆ LoadDungeonMapTile16()

Variable Documentation

◆ kEntranceNames

◆ kGfxBufferOffset

◆ kGfxBufferStride

◆ kGfxBufferAnimatedFrameOffset

◆ kGfxBufferAnimatedFrameStride

◆ kGfxBufferRoomOffset

◆ kGfxBufferRoomSpriteOffset

◆ kGfxBufferRoomSpriteStride

◆ kGfxBufferRoomSpriteLastLineOffset

◆ room_object_layout_pointer

◆ room_object_pointer

◆ dungeons_main_bg_palette_pointers

◆ dungeons_palettes

◆ room_items_pointers

◆ rooms_sprite_pointer

◆ kRoomHeaderPointer

◆ kRoomHeaderPointerBank

◆ gfx_groups_pointer

◆ chests_length_pointer

◆ chests_data_pointer1

◆ messages_id_dungeon

◆ blocks_length

◆ blocks_pointer1

◆ blocks_pointer2

◆ blocks_pointer3

◆ blocks_pointer4

◆ torch_data

◆ torches_length_pointer

◆ sprite_blockset_pointer

◆ sprites_data

◆ sprites_data_empty_room

◆ sprites_end_data

◆ pit_pointer

◆ pit_count

◆ doorPointers

◆ door_gfx_up

◆ door_gfx_down

◆ door_gfx_cavexit_down

◆ door_gfx_left

◆ door_gfx_right

◆ door_pos_up

◆ door_pos_down

◆ door_pos_left

◆ door_pos_right

◆ dungeon_spr_ptrs

◆ NumberOfRooms

◆ stairsObjects

◆ kRoomNames

◆ kEntranceRoom
