Main namespace for the application. More...

Namespaces
namespace	cli
	Namespace for the command line interface.

namespace	core

namespace	editor
	Editors are the view controllers for the application.

namespace	emu
	SNES Emulation and debugging tools.

namespace	gfx
	Contains classes for handling graphical data.

namespace	gui
	Graphical User Interface (GUI) components for the application.

namespace	test

namespace	util

namespace	zelda3
	Zelda 3 specific classes and functions.

Classes
class	GraphicsSheetManager

struct	Project
	Represents a project in the application. More...

class	RecentFilesManager

class	Renderer
	The Renderer class represents the renderer for the Yaze application. More...

struct	ResourceLabelManager

class	Rom
	The Rom class is used to load, save, and modify Rom data. More...

class	SharedRom
	A class to hold a shared pointer to a Rom object. More...

Functions
uint32_t	GetGraphicsAddress (const uint8_t *data, uint8_t addr, uint32_t ptr1, uint32_t ptr2, uint32_t ptr3)

absl::StatusOr< std::vector< uint8_t > >	Load2BppGraphics (const Rom &rom)
	Loads 2bpp graphics from Rom data.

absl::StatusOr< std::array< gfx::Bitmap, kNumLinkSheets > >	LoadLinkGraphics (const Rom &rom)
	Loads the players 4bpp graphics sheet from Rom data.

absl::StatusOr< std::array< gfx::Bitmap, kNumGfxSheets > >	LoadAllGraphicsData (Rom &rom, bool defer_render=false)
	This function iterates over all graphics sheets in the Rom and loads them into memory. Depending on the sheet's index, it may be uncompressed or compressed using the LC-LZ2 algorithm. The uncompressed sheets are 3 bits per pixel (BPP), while the compressed sheets are 4 BPP. The loaded graphics data is converted to 8 BPP and stored in a bitmap.

absl::Status	SaveAllGraphicsData (Rom &rom, std::array< gfx::Bitmap, kNumGfxSheets > &gfx_sheets)

uint32_t	SnesToPc (uint32_t addr) noexcept

uint32_t	PcToSnes (uint32_t addr)

uint32_t	Get24LocalFromPC (uint8_t *data, int addr, bool pc=true)

int	AddressFromBytes (uint8_t bank, uint8_t high, uint8_t low) noexcept

uint32_t	MapBankToWordAddress (uint8_t bank, uint16_t addr) noexcept

Variables
const std::string	kRecentFilesFilename = "recent_files.txt"

constexpr char	kEndOfProjectFile [] = "EndOfProjectFile"

constexpr int	Uncompressed3BPPSize = 0x0600

constexpr uint32_t	kNumGfxSheets = 223

constexpr uint32_t	kNumLinkSheets = 14

constexpr uint32_t	kTile16Ptr = 0x78000

constexpr uint32_t	kNormalGfxSpaceStart = 0x87000

constexpr uint32_t	kNormalGfxSpaceEnd = 0xC4200

constexpr uint32_t	kFontSpriteLocation = 0x70000

constexpr uint32_t	kGfxGroupsPointer = 0x6237

constexpr uint32_t	kUncompressedSheetSize = 0x0800

constexpr uint32_t	kNumMainBlocksets = 37

constexpr uint32_t	kNumRoomBlocksets = 82

constexpr uint32_t	kNumSpritesets = 144

constexpr uint32_t	kNumPalettesets = 72

constexpr uint32_t	kEntranceGfxGroup = 0x5D97

constexpr uint32_t	kMaxGraphics = 0x0C3FFF

constexpr uint32_t	kFastRomRegion = 0x808000

Detailed Description

Main namespace for the application.

Function Documentation

◆ GetGraphicsAddress()

uint32_t yaze::GetGraphicsAddress	(	const uint8_t *	data,
		uint8_t	addr,
		uint32_t	ptr1,
		uint32_t	ptr2,
		uint32_t	ptr3 )

Definition at line 33 of file rom.cc.

References AddressFromBytes(), and SnesToPc().

Referenced by Load2BppGraphics(), LoadAllGraphicsData(), and SaveAllGraphicsData().

Here is the call graph for this function:

◆ Load2BppGraphics()

absl::StatusOr< std::vector< uint8_t > > yaze::Load2BppGraphics ( const Rom & rom )

Loads 2bpp graphics from Rom data.

This function loads 2bpp graphics from Rom data by iterating over a list of sheet IDs, decompressing the sheet data, converting it to 8bpp format, and appending the converted sheet data to a byte vector.

Definition at line 39 of file rom.cc.

References ASSIGN_OR_RETURN, yaze::Rom::data(), yaze::gfx::lc_lz2::DecompressV2(), GetGraphicsAddress(), zelda3_version_pointers::kOverworldGfxPtr1, zelda3_version_pointers::kOverworldGfxPtr2, zelda3_version_pointers::kOverworldGfxPtr3, yaze::gfx::SnesTo8bppSheet(), and yaze::Rom::version_constants().

Referenced by yaze::zelda3::Inventory::BuildTileset().

◆ LoadLinkGraphics()

absl::StatusOr< std::array< gfx::Bitmap, kNumLinkSheets > > yaze::LoadLinkGraphics ( const Rom & rom )

Loads the players 4bpp graphics sheet from Rom data.

Definition at line 58 of file rom.cc.

References ASSIGN_OR_RETURN, yaze::Renderer::GetInstance(), kNumLinkSheets, yaze::gfx::kTilesheetDepth, yaze::gfx::kTilesheetHeight, yaze::gfx::kTilesheetWidth, yaze::Rom::palette_group(), yaze::Rom::ReadByteVector(), yaze::core::Renderer::RenderBitmap(), RETURN_IF_ERROR, and yaze::gfx::SnesTo8bppSheet().

Referenced by yaze::editor::GraphicsEditor::UpdateLinkGfxView().

◆ LoadAllGraphicsData()

absl::StatusOr< std::array< gfx::Bitmap, kNumGfxSheets > > yaze::LoadAllGraphicsData	(	Rom &	rom,
		bool	defer_render = false )

This function iterates over all graphics sheets in the Rom and loads them into memory. Depending on the sheet's index, it may be uncompressed or compressed using the LC-LZ2 algorithm. The uncompressed sheets are 3 bits per pixel (BPP), while the compressed sheets are 4 BPP. The loaded graphics data is converted to 8 BPP and stored in a bitmap.

The graphics sheets are divided into the following ranges:

Range	Compression Type	Decompressed Size	Number of Chars
0-112	Compressed 3bpp BGR	0x600 chars	Decompressed each
113-114	Compressed 2bpp	0x800 chars	Decompressed each
115-126	Uncompressed 3bpp sprites	0x600 chars	Each
127-217	Compressed 3bpp sprites	0x600 chars	Decompressed each
218-222	Compressed 2bpp	0x800 chars	Decompressed each

Definition at line 78 of file rom.cc.

References ASSIGN_OR_RETURN, yaze::Rom::data(), yaze::gfx::lc_lz2::DecompressV2(), GetGraphicsAddress(), yaze::Renderer::GetInstance(), kNumGfxSheets, zelda3_version_pointers::kOverworldGfxPtr1, zelda3_version_pointers::kOverworldGfxPtr2, zelda3_version_pointers::kOverworldGfxPtr3, yaze::gfx::kTilesheetDepth, yaze::gfx::kTilesheetHeight, yaze::gfx::kTilesheetWidth, yaze::Rom::mutable_graphics_buffer(), yaze::Rom::palette_group(), RETURN_IF_ERROR, yaze::gfx::SnesTo8bppSheet(), Uncompressed3BPPSize, and yaze::Rom::version_constants().

Referenced by yaze::editor::EditorManager::Update(), and yaze::editor::Tile16Editor::UpdateTransferTileCanvas().

◆ SaveAllGraphicsData()

absl::Status yaze::SaveAllGraphicsData	(	Rom &	rom,
		std::array< gfx::Bitmap, kNumGfxSheets > &	gfx_sheets )

Definition at line 137 of file rom.cc.

References yaze::Rom::begin(), yaze::gfx::Bpp8SnesToIndexed(), yaze::Rom::data(), GetGraphicsAddress(), yaze::gfx::HyruleMagicCompress(), kNumGfxSheets, zelda3_version_pointers::kOverworldGfxPtr1, zelda3_version_pointers::kOverworldGfxPtr2, zelda3_version_pointers::kOverworldGfxPtr3, and yaze::Rom::version_constants().

Referenced by yaze::editor::EditorManager::SaveRom().

◆ SnesToPc()

uint32_t yaze::SnesToPc ( uint32_t addr )

inlinenoexcept

Definition at line 328 of file rom.h.

References kFastRomRegion.

Referenced by yaze::editor::BuildDictionaryEntries(), yaze::zelda3::Overworld::DecompressAllMapTiles(), Get24LocalFromPC(), GetGraphicsAddress(), yaze::cli::SnesToPcCommand::handle(), yaze::zelda3::Room::LoadAnimatedGraphics(), yaze::zelda3::Room::LoadChests(), yaze::editor::ScreenEditor::LoadDungeonMaps(), yaze::Rom::LoadGfxGroups(), yaze::zelda3::Room::LoadHeader(), yaze::zelda3::Overworld::LoadItems(), yaze::zelda3::Room::LoadObjects(), yaze::zelda3::Room::LoadRoomFromROM(), yaze::zelda3::Room::LoadSprites(), yaze::zelda3::Overworld::LoadSpritesFromMap(), yaze::zelda3::TitleScreen::LoadTitleScreen(), yaze::editor::ScreenEditor::SaveDungeonMaps(), yaze::Rom::SaveGroupsToRom(), yaze::zelda3::Overworld::SaveMap16Expanded(), and yaze::editor::MemoryEditorWithDiffChecker::Update().

◆ PcToSnes()

uint32_t yaze::PcToSnes ( uint32_t addr )

inline

Definition at line 336 of file rom.h.

Referenced by Get24LocalFromPC(), yaze::cli::PcToSnesCommand::handle(), yaze::zelda3::Overworld::SaveItems(), yaze::zelda3::Overworld::SaveMap16Expanded(), yaze::zelda3::Overworld::SaveMap32Expanded(), and yaze::zelda3::Overworld::SaveOverworldMaps().

◆ Get24LocalFromPC()

uint32_t yaze::Get24LocalFromPC	(	uint8_t *	data,
		int	addr,
		bool	pc = true )

inline

Definition at line 349 of file rom.h.

References PcToSnes(), and SnesToPc().

Referenced by yaze::editor::ParseSingleMessage(), yaze::editor::MessageEditor::ReadAllTextData(), and yaze::editor::MessageEditor::ReadAllTextDataV2().

Here is the call graph for this function:

◆ AddressFromBytes()

int yaze::AddressFromBytes	(	uint8_t	bank,
		uint8_t	high,
		uint8_t	low )

inlinenoexcept

Definition at line 358 of file rom.h.

Referenced by GetGraphicsAddress().

◆ MapBankToWordAddress()

uint32_t yaze::MapBankToWordAddress	(	uint8_t	bank,
		uint16_t	addr )

inlinenoexcept

Definition at line 362 of file rom.h.

Variable Documentation

◆ kRecentFilesFilename

const std::string yaze::kRecentFilesFilename = "recent_files.txt"

Definition at line 14 of file project.h.

Referenced by yaze::RecentFilesManager::RecentFilesManager().

◆ kEndOfProjectFile

char yaze::kEndOfProjectFile[] = "EndOfProjectFile"

constexpr

Definition at line 15 of file project.h.

Referenced by yaze::Project::Open(), and yaze::Project::Save().

◆ Uncompressed3BPPSize

int yaze::Uncompressed3BPPSize = 0x0600

constexpr

Definition at line 31 of file rom.cc.

Referenced by LoadAllGraphicsData().

◆ kNumGfxSheets

uint32_t yaze::kNumGfxSheets = 223

constexpr

Definition at line 30 of file rom.h.

Referenced by yaze::gui::GfxSheetAssetBrowser::Initialize(), LoadAllGraphicsData(), SaveAllGraphicsData(), and yaze::editor::GraphicsEditor::UpdateGfxSheetList().

◆ kNumLinkSheets

uint32_t yaze::kNumLinkSheets = 14

constexpr

Definition at line 31 of file rom.h.

Referenced by LoadLinkGraphics().

◆ kTile16Ptr

uint32_t yaze::kTile16Ptr = 0x78000

constexpr

Definition at line 32 of file rom.h.

Referenced by yaze::Rom::ReadTile16(), and yaze::Rom::WriteTile16().

◆ kNormalGfxSpaceStart

uint32_t yaze::kNormalGfxSpaceStart = 0x87000

constexpr

Definition at line 33 of file rom.h.

◆ kNormalGfxSpaceEnd

uint32_t yaze::kNormalGfxSpaceEnd = 0xC4200

constexpr

Definition at line 34 of file rom.h.

◆ kFontSpriteLocation

uint32_t yaze::kFontSpriteLocation = 0x70000

constexpr

Definition at line 35 of file rom.h.

◆ kGfxGroupsPointer

uint32_t yaze::kGfxGroupsPointer = 0x6237

constexpr

Definition at line 36 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kUncompressedSheetSize

uint32_t yaze::kUncompressedSheetSize = 0x0800

constexpr

Definition at line 37 of file rom.h.

◆ kNumMainBlocksets

uint32_t yaze::kNumMainBlocksets = 37

constexpr

Definition at line 38 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kNumRoomBlocksets

uint32_t yaze::kNumRoomBlocksets = 82

constexpr

Definition at line 39 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kNumSpritesets

uint32_t yaze::kNumSpritesets = 144

constexpr

Definition at line 40 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kNumPalettesets

uint32_t yaze::kNumPalettesets = 72

constexpr

Definition at line 41 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kEntranceGfxGroup

uint32_t yaze::kEntranceGfxGroup = 0x5D97

constexpr

Definition at line 42 of file rom.h.

Referenced by yaze::Rom::LoadGfxGroups(), and yaze::Rom::SaveGroupsToRom().

◆ kMaxGraphics

uint32_t yaze::kMaxGraphics = 0x0C3FFF

constexpr

Definition at line 43 of file rom.h.

◆ kFastRomRegion

uint32_t yaze::kFastRomRegion = 0x808000

constexpr

Definition at line 326 of file rom.h.

Referenced by SnesToPc().
