yaze::editor::OracleRamPanel Class Reference

Panel for live monitoring of Oracle of Secrets RAM variables. More...

#include <oracle_ram_panel.h>

Inheritance diagram for yaze::editor::OracleRamPanel:

Collaboration diagram for yaze::editor::OracleRamPanel:

Classes
struct	RamVariable

Public Member Functions
	OracleRamPanel ()
	~OracleRamPanel () override=default
std::string	GetId () const override
	Unique identifier for this panel.
std::string	GetDisplayName () const override
	Human-readable name shown in menus and title bars.
std::string	GetIcon () const override
	Material Design icon for this panel.
std::string	GetEditorCategory () const override
	Editor category this panel belongs to.
PanelCategory	GetPanelCategory () const override
	Get the lifecycle category for this panel.
void	Draw (bool *p_open) override
	Draw the panel content.
void	OnOpen () override
	Called when panel becomes visible.
Public Member Functions inherited from yaze::editor::EditorPanel
virtual	~EditorPanel ()=default
virtual void	OnFirstDraw ()
	Called once before the first Draw() in a session.
virtual bool	RequiresLazyInit () const
	Whether this panel uses lazy initialization.
void	InvalidateLazyInit ()
	Reset lazy init state so OnFirstDraw() runs again.
virtual void	OnClose ()
	Called when panel is hidden.
virtual void	OnFocus ()
	Called when panel receives focus.
virtual PanelContextScope	GetContextScope () const
	Optional context binding for this panel (room/selection/etc)
virtual PanelScope	GetScope () const
	Get the registration scope for this panel.
virtual bool	IsEnabled () const
	Check if this panel is currently enabled.
virtual std::string	GetDisabledTooltip () const
	Get tooltip text when panel is disabled.
virtual std::string	GetShortcutHint () const
	Get keyboard shortcut hint for display.
virtual int	GetPriority () const
	Get display priority for menu ordering.
virtual float	GetPreferredWidth () const
	Get preferred width for this panel (optional)
virtual bool	IsVisibleByDefault () const
	Whether this panel should be visible by default.
virtual std::string	GetParentPanelId () const
	Get parent panel ID for cascade behavior.
virtual bool	CascadeCloseChildren () const
	Whether closing this panel should close child panels.
void	DrawWithLazyInit (bool *p_open)
	Execute lazy initialization if needed, then call Draw()

Private Member Functions
void	InitializeVariables ()
void	RefreshVariables ()
void	DrawVariableTable ()

Private Attributes
std::vector< RamVariable >	variables_
double	last_refresh_time_ = 0.0
bool	auto_refresh_ = true

Additional Inherited Members
Protected Member Functions inherited from yaze::editor::EditorPanel
void	InvalidateCache ()
	Invalidate all cached computations.
template<typename T >
T &	GetCached (const std::string &key, std::function< T()> compute)
	Get or compute a cached value.
bool	IsCacheValid () const
	Check if cache has been invalidated.
void	ClearCache ()
	Clear all cached values (more aggressive than InvalidateCache)

Detailed Description

Panel for live monitoring of Oracle of Secrets RAM variables.

Definition at line 17 of file oracle_ram_panel.h.

Constructor & Destructor Documentation

OracleRamPanel()

yaze::editor::OracleRamPanel::OracleRamPanel

(

)

Definition at line 15 of file oracle_ram_panel.cc.

References InitializeVariables().

Here is the call graph for this function:

~OracleRamPanel()

yaze::editor::OracleRamPanel::~OracleRamPanel ( )

overridedefault

Member Function Documentation

GetId()

std::string yaze::editor::OracleRamPanel::GetId ( ) const

inlineoverridevirtual

Unique identifier for this panel.

Returns

Panel ID in format "{category}.{name}" (e.g., "dungeon.room_selector")

IDs should be:

• Lowercase with underscores
• Prefixed with editor category
• Unique across all panels

Implements yaze::editor::EditorPanel.

Definition at line 23 of file oracle_ram_panel.h.

GetDisplayName()

std::string yaze::editor::OracleRamPanel::GetDisplayName ( ) const

inlineoverridevirtual

Human-readable name shown in menus and title bars.

Returns

Display name (e.g., "Room Selector")

Implements yaze::editor::EditorPanel.

Definition at line 24 of file oracle_ram_panel.h.

GetIcon()

std::string yaze::editor::OracleRamPanel::GetIcon ( ) const

overridevirtual

Material Design icon for this panel.

Returns

Icon constant (e.g., ICON_MD_LIST)

Implements yaze::editor::EditorPanel.

Definition at line 19 of file oracle_ram_panel.cc.

References ICON_MD_MEMORY.

GetEditorCategory()

std::string yaze::editor::OracleRamPanel::GetEditorCategory ( ) const

inlineoverridevirtual

Editor category this panel belongs to.

Returns

Category name matching EditorType (e.g., "Dungeon", "Overworld")

Implements yaze::editor::EditorPanel.

Definition at line 26 of file oracle_ram_panel.h.

GetPanelCategory()

PanelCategory yaze::editor::OracleRamPanel::GetPanelCategory ( ) const

inlineoverridevirtual

Get the lifecycle category for this panel.

Returns

PanelCategory determining visibility behavior on editor switch

Default is EditorBound (hidden when switching editors).

Reimplemented from yaze::editor::EditorPanel.

Definition at line 27 of file oracle_ram_panel.h.

References yaze::editor::Persistent.

Draw()

void yaze::editor::OracleRamPanel::Draw ( bool * p_open )

overridevirtual

Draw the panel content.

Parameters

p_open

Pointer to visibility flag (nullptr if not closable)

Called by PanelManager when the panel is visible. Do NOT call ImGui::Begin/End - the PanelWindow wrapper handles that. Just draw your content directly.

Implements yaze::editor::EditorPanel.

Definition at line 73 of file oracle_ram_panel.cc.

References auto_refresh_, DrawVariableTable(), ICON_MD_PAUSE, ICON_MD_PLAY_ARROW, ICON_MD_REFRESH, last_refresh_time_, and RefreshVariables().

Here is the call graph for this function:

OnOpen()

void yaze::editor::OracleRamPanel::OnOpen ( )

overridevirtual

Called when panel becomes visible.

Use this to initialize state, load resources, or start animations. Called after the panel is shown but before first Draw().

Reimplemented from yaze::editor::EditorPanel.

Definition at line 23 of file oracle_ram_panel.cc.

References RefreshVariables().

Here is the call graph for this function:

InitializeVariables()

void yaze::editor::OracleRamPanel::InitializeVariables ( )

private

Definition at line 27 of file oracle_ram_panel.cc.

References variables_.

Referenced by OracleRamPanel().

RefreshVariables()

void yaze::editor::OracleRamPanel::RefreshVariables ( )

private

Definition at line 50 of file oracle_ram_panel.cc.

References yaze::emu::mesen::MesenClientRegistry::GetOrCreate(), and variables_.

Referenced by Draw(), and OnOpen().

Here is the call graph for this function:

DrawVariableTable()

void yaze::editor::OracleRamPanel::DrawVariableTable ( )

private

Definition at line 97 of file oracle_ram_panel.cc.

References variables_.

Referenced by Draw().

Member Data Documentation

variables_

std::vector<RamVariable> yaze::editor::OracleRamPanel::variables_

private

Definition at line 45 of file oracle_ram_panel.h.

Referenced by DrawVariableTable(), InitializeVariables(), and RefreshVariables().

last_refresh_time_

double yaze::editor::OracleRamPanel::last_refresh_time_ = 0.0

private

Definition at line 46 of file oracle_ram_panel.h.

Referenced by Draw().

auto_refresh_

bool yaze::editor::OracleRamPanel::auto_refresh_ = true

private

Definition at line 47 of file oracle_ram_panel.h.

Referenced by Draw().

---

The documentation for this class was generated from the following files:

• src/app/editor/agent/oracle_ram_panel.h
• src/app/editor/agent/oracle_ram_panel.cc
