yaze::editor::InteractionModeManager Class Reference

Manages interaction mode state and transitions. More...

#include <interaction_mode.h>

Collaboration diagram for yaze::editor::InteractionModeManager:

Public Member Functions
InteractionMode	GetMode () const
	Get current interaction mode.
InteractionMode	GetPreviousMode () const
	Get previous mode (for undo/escape handling)
void	SetMode (InteractionMode mode)
	Set interaction mode.
void	CancelCurrentMode ()
	Cancel current mode and return to Select.
bool	IsPlacementActive () const
	Check if any placement mode is active.
bool	IsSelectMode () const
	Check if in normal selection mode.
bool	IsDragging () const
	Check if any dragging operation is in progress.
bool	IsRectangleSelecting () const
	Check if rectangle selection is in progress.
bool	IsObjectPlacementActive () const
	Check if object placement mode is active.
bool	IsDoorPlacementActive () const
	Check if door placement mode is active.
bool	IsSpritePlacementActive () const
	Check if sprite placement mode is active.
bool	IsItemPlacementActive () const
	Check if item placement mode is active.
bool	IsEntityPlacementActive () const
	Check if entity (non-object) placement is active.
ModeState &	GetModeState ()
	Get mutable reference to mode state.
const ModeState &	GetModeState () const
	Get const reference to mode state.
const char *	GetModeName () const
	Get mode name for debugging/UI.

Private Attributes
InteractionMode	current_mode_ = InteractionMode::Select
InteractionMode	previous_mode_ = InteractionMode::Select
ModeState	mode_state_

Detailed Description

Manages interaction mode state and transitions.

Provides a unified interface for mode management, replacing scattered boolean flags with explicit state machine semantics.

Usage: InteractionModeManager mode_manager;

// Enter placement mode mode_manager.SetMode(InteractionMode::PlaceObject); mode_manager.GetModeState().preview_object = some_object;

// Query mode if (mode_manager.IsPlacementActive()) { ... }

// Cancel and return to select mode_manager.CancelCurrentMode();

Definition at line 143 of file interaction_mode.h.

Member Function Documentation

GetMode()

InteractionMode yaze::editor::InteractionModeManager::GetMode ( ) const

inline

Get current interaction mode.

Definition at line 148 of file interaction_mode.h.

References current_mode_.

Referenced by yaze::editor::DungeonObjectInteraction::CancelDoorPlacement(), yaze::editor::DungeonObjectInteraction::CancelItemPlacement(), yaze::editor::DungeonObjectInteraction::CancelSpritePlacement(), yaze::editor::DungeonObjectInteraction::ClearEntitySelection(), yaze::editor::DungeonObjectInteraction::ClearSelection(), yaze::editor::DungeonObjectInteraction::DrawDoorGhostPreview(), yaze::editor::DungeonObjectInteraction::DrawDoorSnapIndicators(), yaze::editor::DungeonObjectInteraction::DrawDragPreview(), yaze::editor::DungeonObjectInteraction::DrawEntitySelectionHighlights(), yaze::editor::DungeonObjectInteraction::DrawGhostPreview(), yaze::editor::DungeonObjectInteraction::DrawItemGhostPreview(), yaze::editor::DungeonObjectInteraction::DrawSpriteGhostPreview(), yaze::editor::DungeonObjectInteraction::HandleCanvasMouseInput(), yaze::editor::DungeonObjectInteraction::HandleEntityDrag(), yaze::editor::DungeonObjectInteraction::IsDoorPlacementActive(), yaze::editor::DungeonObjectInteraction::IsItemPlacementActive(), yaze::editor::DungeonObjectInteraction::IsObjectLoaded(), yaze::editor::DungeonObjectInteraction::IsSpritePlacementActive(), yaze::editor::DungeonObjectInteraction::PlaceDoorAtPosition(), yaze::editor::DungeonObjectInteraction::PlaceItemAtPosition(), yaze::editor::DungeonObjectInteraction::PlaceSpriteAtPosition(), yaze::editor::DungeonObjectInteraction::SetDoorPlacementMode(), yaze::editor::DungeonObjectInteraction::SetItemPlacementMode(), yaze::editor::DungeonObjectInteraction::SetPreviewObject(), and yaze::editor::DungeonObjectInteraction::SetSpritePlacementMode().

GetPreviousMode()

InteractionMode yaze::editor::InteractionModeManager::GetPreviousMode ( ) const

inline

Get previous mode (for undo/escape handling)

Definition at line 153 of file interaction_mode.h.

References previous_mode_.

SetMode()

void yaze::editor::InteractionModeManager::SetMode

(

InteractionMode

mode

)

Set interaction mode.

Clears appropriate state data when transitioning between modes.

Parameters

mode	The new mode to enter

Definition at line 6 of file interaction_mode.cc.

References yaze::editor::ModeState::ClearDragData(), yaze::editor::ModeState::ClearPlacementData(), yaze::editor::ModeState::ClearRectangleData(), current_mode_, yaze::editor::DraggingEntity, yaze::editor::DraggingObjects, mode_state_, yaze::editor::PlaceDoor, yaze::editor::PlaceItem, yaze::editor::PlaceObject, yaze::editor::PlaceSprite, previous_mode_, yaze::editor::RectangleSelect, and yaze::editor::Select.

Referenced by yaze::editor::DungeonObjectInteraction::ClearEntitySelection(), yaze::editor::DungeonObjectInteraction::ClearSelection(), yaze::editor::DungeonObjectInteraction::HandleCanvasMouseInput(), yaze::editor::DungeonObjectInteraction::HandleEntityDrag(), yaze::editor::DungeonObjectInteraction::SetDoorPlacementMode(), yaze::editor::DungeonObjectInteraction::SetItemPlacementMode(), yaze::editor::DungeonObjectInteraction::SetPreviewObject(), yaze::editor::DungeonObjectInteraction::SetSpritePlacementMode(), and yaze::editor::DungeonObjectInteraction::TrySelectEntityAtCursor().

Here is the call graph for this function:

CancelCurrentMode()

void yaze::editor::InteractionModeManager::CancelCurrentMode

(

)

Cancel current mode and return to Select.

Clears mode-specific state and returns to normal selection mode.

Definition at line 43 of file interaction_mode.cc.

References yaze::editor::ModeState::Clear(), current_mode_, mode_state_, previous_mode_, and yaze::editor::Select.

Referenced by yaze::editor::DungeonObjectInteraction::CancelDoorPlacement(), yaze::editor::DungeonObjectInteraction::CancelItemPlacement(), yaze::editor::DungeonObjectInteraction::CancelPlacement(), and yaze::editor::DungeonObjectInteraction::CancelSpritePlacement().

Here is the call graph for this function:

IsPlacementActive()

bool yaze::editor::InteractionModeManager::IsPlacementActive ( ) const

inline

Check if any placement mode is active.

Definition at line 173 of file interaction_mode.h.

References current_mode_, yaze::editor::PlaceDoor, yaze::editor::PlaceItem, yaze::editor::PlaceObject, and yaze::editor::PlaceSprite.

Referenced by yaze::editor::DungeonObjectInteraction::HandleCanvasMouseInput(), and yaze::editor::DungeonObjectInteraction::HandleScrollWheelResize().

IsSelectMode()

bool yaze::editor::InteractionModeManager::IsSelectMode ( ) const

inline

Check if in normal selection mode.

Definition at line 183 of file interaction_mode.h.

References current_mode_, and yaze::editor::Select.

IsDragging()

bool yaze::editor::InteractionModeManager::IsDragging ( ) const

inline

Check if any dragging operation is in progress.

Definition at line 188 of file interaction_mode.h.

References current_mode_, yaze::editor::DraggingEntity, and yaze::editor::DraggingObjects.

IsRectangleSelecting()

bool yaze::editor::InteractionModeManager::IsRectangleSelecting ( ) const

inline

Check if rectangle selection is in progress.

Definition at line 196 of file interaction_mode.h.

References current_mode_, and yaze::editor::RectangleSelect.

IsObjectPlacementActive()

bool yaze::editor::InteractionModeManager::IsObjectPlacementActive ( ) const

inline

Check if object placement mode is active.

Definition at line 203 of file interaction_mode.h.

References current_mode_, and yaze::editor::PlaceObject.

Referenced by yaze::editor::DungeonObjectInteraction::PlaceObjectAtPosition().

IsDoorPlacementActive()

bool yaze::editor::InteractionModeManager::IsDoorPlacementActive ( ) const

inline

Check if door placement mode is active.

Definition at line 210 of file interaction_mode.h.

References current_mode_, and yaze::editor::PlaceDoor.

IsSpritePlacementActive()

bool yaze::editor::InteractionModeManager::IsSpritePlacementActive ( ) const

inline

Check if sprite placement mode is active.

Definition at line 217 of file interaction_mode.h.

References current_mode_, and yaze::editor::PlaceSprite.

IsItemPlacementActive()

bool yaze::editor::InteractionModeManager::IsItemPlacementActive ( ) const

inline

Check if item placement mode is active.

Definition at line 224 of file interaction_mode.h.

References current_mode_, and yaze::editor::PlaceItem.

IsEntityPlacementActive()

bool yaze::editor::InteractionModeManager::IsEntityPlacementActive ( ) const

inline

Check if entity (non-object) placement is active.

Definition at line 231 of file interaction_mode.h.

References current_mode_, yaze::editor::PlaceDoor, yaze::editor::PlaceItem, and yaze::editor::PlaceSprite.

GetModeState() [1/2]

ModeState & yaze::editor::InteractionModeManager::GetModeState ( )

inline

Get mutable reference to mode state.

Definition at line 240 of file interaction_mode.h.

References mode_state_.

Referenced by yaze::editor::DungeonObjectInteraction::DrawDoorGhostPreview(), yaze::editor::DungeonObjectInteraction::DrawDoorSnapIndicators(), yaze::editor::DungeonObjectInteraction::DrawDragPreview(), yaze::editor::DungeonObjectInteraction::DrawEntitySelectionHighlights(), yaze::editor::DungeonObjectInteraction::GetPreviewDoorType(), yaze::editor::DungeonObjectInteraction::GetPreviewItemId(), yaze::editor::DungeonObjectInteraction::GetPreviewSpriteId(), yaze::editor::DungeonObjectInteraction::HandleCanvasMouseInput(), yaze::editor::DungeonObjectInteraction::HandleEntityDrag(), yaze::editor::DungeonObjectInteraction::SetDoorPlacementMode(), yaze::editor::DungeonObjectInteraction::SetItemPlacementMode(), yaze::editor::DungeonObjectInteraction::SetPreviewDoorType(), yaze::editor::DungeonObjectInteraction::SetPreviewItemId(), yaze::editor::DungeonObjectInteraction::SetPreviewObject(), yaze::editor::DungeonObjectInteraction::SetPreviewSpriteId(), yaze::editor::DungeonObjectInteraction::SetSpritePlacementMode(), and yaze::editor::DungeonObjectInteraction::TrySelectEntityAtCursor().

GetModeState() [2/2]

const ModeState & yaze::editor::InteractionModeManager::GetModeState ( ) const

inline

Get const reference to mode state.

Definition at line 245 of file interaction_mode.h.

References mode_state_.

GetModeName()

const char * yaze::editor::InteractionModeManager::GetModeName

(

)

const

Get mode name for debugging/UI.

Definition at line 50 of file interaction_mode.cc.

References current_mode_, yaze::editor::DraggingEntity, yaze::editor::DraggingObjects, yaze::editor::PlaceDoor, yaze::editor::PlaceItem, yaze::editor::PlaceObject, yaze::editor::PlaceSprite, yaze::editor::RectangleSelect, and yaze::editor::Select.

Member Data Documentation

current_mode_

InteractionMode yaze::editor::InteractionModeManager::current_mode_ = InteractionMode::Select

private

Definition at line 253 of file interaction_mode.h.

Referenced by CancelCurrentMode(), GetMode(), GetModeName(), IsDoorPlacementActive(), IsDragging(), IsEntityPlacementActive(), IsItemPlacementActive(), IsObjectPlacementActive(), IsPlacementActive(), IsRectangleSelecting(), IsSelectMode(), IsSpritePlacementActive(), and SetMode().

previous_mode_

InteractionMode yaze::editor::InteractionModeManager::previous_mode_ = InteractionMode::Select

private

Definition at line 254 of file interaction_mode.h.

Referenced by CancelCurrentMode(), GetPreviousMode(), and SetMode().

mode_state_

ModeState yaze::editor::InteractionModeManager::mode_state_

private

Definition at line 255 of file interaction_mode.h.

Referenced by CancelCurrentMode(), GetModeState(), GetModeState(), and SetMode().

---

The documentation for this class was generated from the following files:

• src/app/editor/dungeon/interaction/interaction_mode.h
• src/app/editor/dungeon/interaction/interaction_mode.cc
