yaze::editor::MessagePreview Struct Reference

#include <message_preview.h>

Public Member Functions
	MessagePreview ()
void	DrawTileToPreview (int x, int y, int srcx, int srcy, int pal, int sizex=1, int sizey=1)
void	DrawStringToPreview (const std::string &str)
void	DrawCharacterToPreview (char c)
void	DrawCharacterToPreview (const std::vector< uint8_t > &text)
void	DrawMessagePreview (const MessageData &message)

Public Attributes
bool	skip_next = false
int	text_line = 0
int	text_position = 0
int	shown_lines = 0
std::array< uint8_t, kWidthArraySize >	width_array = {0}
std::vector< uint8_t >	font_gfx16_data_
std::vector< uint8_t >	font_gfx16_data_2_
std::vector< uint8_t >	current_preview_data_
std::vector< DictionaryEntry >	all_dictionaries_

Detailed Description

Definition at line 15 of file message_preview.h.

Constructor & Destructor Documentation

MessagePreview()

yaze::editor::MessagePreview::MessagePreview ( )

inline

Definition at line 16 of file message_preview.h.

References current_preview_data_, yaze::editor::kCurrentMessageHeight, and yaze::editor::kCurrentMessageWidth.

Member Function Documentation

DrawTileToPreview()

void yaze::editor::MessagePreview::DrawTileToPreview	(	int	x,
		int	y,
		int	srcx,
		int	srcy,
		int	pal,
		int	sizex = 1,
		int	sizey = 1 )

Definition at line 6 of file message_preview.cc.

References current_preview_data_, and font_gfx16_data_2_.

Referenced by DrawCharacterToPreview().

DrawStringToPreview()

void yaze::editor::MessagePreview::DrawStringToPreview

(

const std::string &

str

)

Definition at line 35 of file message_preview.cc.

References DrawCharacterToPreview().

Referenced by DrawCharacterToPreview().

Here is the call graph for this function:

DrawCharacterToPreview() [1/2]

void yaze::editor::MessagePreview::DrawCharacterToPreview

(

char

c

)

Definition at line 41 of file message_preview.cc.

References DrawCharacterToPreview(), and yaze::editor::FindMatchingCharacter().

Referenced by DrawCharacterToPreview(), DrawCharacterToPreview(), DrawMessagePreview(), and DrawStringToPreview().

Here is the call graph for this function:

DrawCharacterToPreview() [2/2]

void yaze::editor::MessagePreview::DrawCharacterToPreview

(

const std::vector< uint8_t > &

text

)

Definition at line 47 of file message_preview.cc.

References all_dictionaries_, yaze::editor::DICTOFF, DrawCharacterToPreview(), DrawStringToPreview(), DrawTileToPreview(), yaze::editor::FindRealDictionaryEntry(), yaze::editor::kLine1, yaze::editor::kLine2, yaze::editor::kLine3, yaze::editor::kScrollVertical, skip_next, text_line, text_position, and width_array.

Here is the call graph for this function:

DrawMessagePreview()

void yaze::editor::MessagePreview::DrawMessagePreview

(

const MessageData &

message

)

Definition at line 107 of file message_preview.cc.

References current_preview_data_, yaze::editor::MessageData::Data, DrawCharacterToPreview(), shown_lines, text_line, and text_position.

Here is the call graph for this function:

Member Data Documentation

skip_next

bool yaze::editor::MessagePreview::skip_next = false

Definition at line 29 of file message_preview.h.

Referenced by DrawCharacterToPreview().

text_line

int yaze::editor::MessagePreview::text_line = 0

Definition at line 30 of file message_preview.h.

Referenced by DrawCharacterToPreview(), and DrawMessagePreview().

text_position

int yaze::editor::MessagePreview::text_position = 0

Definition at line 31 of file message_preview.h.

Referenced by DrawCharacterToPreview(), and DrawMessagePreview().

shown_lines

int yaze::editor::MessagePreview::shown_lines = 0

Definition at line 32 of file message_preview.h.

Referenced by DrawMessagePreview().

width_array

std::array<uint8_t, kWidthArraySize> yaze::editor::MessagePreview::width_array = {0}

Definition at line 34 of file message_preview.h.

Referenced by DrawCharacterToPreview().

font_gfx16_data_

std::vector<uint8_t> yaze::editor::MessagePreview::font_gfx16_data_

Definition at line 35 of file message_preview.h.

font_gfx16_data_2_

std::vector<uint8_t> yaze::editor::MessagePreview::font_gfx16_data_2_

Definition at line 36 of file message_preview.h.

Referenced by DrawTileToPreview().

current_preview_data_

std::vector<uint8_t> yaze::editor::MessagePreview::current_preview_data_

Definition at line 37 of file message_preview.h.

Referenced by DrawMessagePreview(), DrawTileToPreview(), and MessagePreview().

all_dictionaries_

std::vector<DictionaryEntry> yaze::editor::MessagePreview::all_dictionaries_

Definition at line 38 of file message_preview.h.

Referenced by DrawCharacterToPreview().

---

The documentation for this struct was generated from the following files:

• src/app/editor/message/message_preview.h
• src/app/editor/message/message_preview.cc
