Provider for symbol (label) resolution in disassembly. More...

#include <symbol_provider.h>

Public Member Functions
	SymbolProvider ()=default

absl::Status	LoadAsarAsmFile (const std::string &path)
	Load symbols from an Asar-style ASM file (usdasm format)

absl::Status	LoadAsarAsmDirectory (const std::string &directory_path)
	Load symbols from a directory of ASM files.

absl::Status	LoadSymbolFile (const std::string &path, SymbolFormat format=SymbolFormat::kAuto)
	Load symbols from a .sym file (various formats)

void	AddSymbol (const Symbol &symbol)
	Add a single symbol manually.

void	AddAsarSymbols (const std::vector< Symbol > &symbols)
	Add symbols from Asar patch results.

void	Clear ()
	Clear all loaded symbols.

std::string	GetSymbolName (uint32_t address) const
	Get symbol name for an address.

std::optional< Symbol >	GetSymbol (uint32_t address) const
	Get full symbol info for an address.

std::vector< Symbol >	GetSymbolsAtAddress (uint32_t address) const
	Get all symbols at an address (there may be multiple)

std::optional< Symbol >	FindSymbol (const std::string &name) const
	Find symbol by name.

std::vector< Symbol >	FindSymbolsMatching (const std::string &pattern) const
	Find symbols matching a pattern (supports wildcards)

std::vector< Symbol >	GetSymbolsInRange (uint32_t start, uint32_t end) const
	Get all symbols in an address range.

std::optional< Symbol >	GetNearestSymbol (uint32_t address) const
	Get nearest symbol at or before an address.

std::string	FormatAddress (uint32_t address, uint32_t max_offset=0x100) const
	Format an address with symbol info.

size_t	GetSymbolCount () const
	Get total number of loaded symbols.

bool	HasSymbols () const
	Check if any symbols are loaded.

std::function< std::string(uint32_t)>	CreateResolver () const
	Create a symbol resolver function for the disassembler.

Private Member Functions
absl::Status	ParseAsarAsmContent (const std::string &content, const std::string &filename)

absl::Status	ParseWlaDxSymFile (const std::string &content)

absl::Status	ParseMesenMlbFile (const std::string &content)

absl::Status	ParseBsnesSymFile (const std::string &content)

SymbolFormat	DetectFormat (const std::string &content, const std::string &extension) const

Private Attributes
std::multimap< uint32_t, Symbol >	symbols_by_address_

std::map< std::string, Symbol >	symbols_by_name_

Detailed Description

Provider for symbol (label) resolution in disassembly.

This class manages symbol tables from multiple sources:

Parsed ASM files (usdasm disassembly)
Symbol files from various emulators/assemblers
Asar patches (runtime symbols)

AI agents use this to see meaningful label names instead of raw addresses when debugging 65816 assembly code.

Usage: SymbolProvider symbols; symbols.LoadAsarAsmFile("bank_00.asm"); symbols.LoadAsarAsmFile("bank_01.asm");

auto name = symbols.GetSymbolName(0x008034); // Returns "MainGameLoop" auto addr = symbols.FindSymbol("Reset"); // Returns Symbol at $008000

Definition at line 66 of file symbol_provider.h.

Constructor & Destructor Documentation

◆ SymbolProvider()

yaze::emu::debug::SymbolProvider::SymbolProvider ( )

default

Member Function Documentation

◆ LoadAsarAsmFile()

absl::Status yaze::emu::debug::SymbolProvider::LoadAsarAsmFile ( const std::string & path )

Load symbols from an Asar-style ASM file (usdasm format)

Parses labels like: MainGameLoop: #_008034: LDA.b $12

Parameters

path	Path to .asm file

Returns: Status indicating success or failure

Definition at line 120 of file symbol_provider.cc.

References ParseAsarAsmContent().

Referenced by LoadAsarAsmDirectory().

Here is the call graph for this function:

◆ LoadAsarAsmDirectory()

absl::Status yaze::emu::debug::SymbolProvider::LoadAsarAsmDirectory ( const std::string & directory_path )

Load symbols from a directory of ASM files.

Scans for all bank_XX.asm files and loads them

Parameters

directory_path Path to directory containing ASM files

Returns: Status indicating success or failure

Definition at line 129 of file symbol_provider.cc.

References LoadAsarAsmFile().

Referenced by yaze::agent::EmulatorServiceImpl::LoadSymbols().

Here is the call graph for this function:

◆ LoadSymbolFile()

absl::Status yaze::emu::debug::SymbolProvider::LoadSymbolFile	(	const std::string &	path,
		SymbolFormat	format = SymbolFormat::kAuto )

Load symbols from a .sym file (various formats)

Parameters

path	Path to symbol file
format	Symbol file format (kAuto for auto-detect)

Returns: Status indicating success or failure

Definition at line 166 of file symbol_provider.cc.

References DetectFormat(), yaze::emu::debug::kAsar, yaze::emu::debug::kAuto, yaze::emu::debug::kBsnes, yaze::emu::debug::kMesen, yaze::emu::debug::kNo$snes, yaze::emu::debug::kWlaDx, ParseAsarAsmContent(), ParseBsnesSymFile(), ParseMesenMlbFile(), and ParseWlaDxSymFile().

Referenced by yaze::agent::EmulatorServiceImpl::LoadSymbols().

◆ AddSymbol()

void yaze::emu::debug::SymbolProvider::AddSymbol ( const Symbol & symbol )

Add a single symbol manually.

Definition at line 196 of file symbol_provider.cc.

References yaze::emu::debug::Symbol::address, yaze::emu::debug::Symbol::name, symbols_by_address_, and symbols_by_name_.

Referenced by AddAsarSymbols(), ParseAsarAsmContent(), ParseBsnesSymFile(), ParseMesenMlbFile(), and ParseWlaDxSymFile().

◆ AddAsarSymbols()

void yaze::emu::debug::SymbolProvider::AddAsarSymbols ( const std::vector< Symbol > & symbols )

Add symbols from Asar patch results.

Definition at line 201 of file symbol_provider.cc.

References AddSymbol().

Here is the call graph for this function:

◆ Clear()

void yaze::emu::debug::SymbolProvider::Clear ( )

Clear all loaded symbols.

Definition at line 207 of file symbol_provider.cc.

References symbols_by_address_, and symbols_by_name_.

◆ GetSymbolName()

std::string yaze::emu::debug::SymbolProvider::GetSymbolName ( uint32_t address ) const

Get symbol name for an address.

Returns: Symbol name if found, empty string otherwise

Definition at line 212 of file symbol_provider.cc.

References symbols_by_address_.

Referenced by CreateResolver().

◆ GetSymbol()

std::optional< Symbol > yaze::emu::debug::SymbolProvider::GetSymbol ( uint32_t address ) const

Get full symbol info for an address.

Returns: Symbol if found, nullopt otherwise

Definition at line 220 of file symbol_provider.cc.

References symbols_by_address_.

Referenced by FormatAddress(), and yaze::agent::EmulatorServiceImpl::GetSymbolAt().

◆ GetSymbolsAtAddress()

std::vector< Symbol > yaze::emu::debug::SymbolProvider::GetSymbolsAtAddress ( uint32_t address ) const

Get all symbols at an address (there may be multiple)

Definition at line 228 of file symbol_provider.cc.

References symbols_by_address_.

◆ FindSymbol()

std::optional< Symbol > yaze::emu::debug::SymbolProvider::FindSymbol ( const std::string & name ) const

Find symbol by name.

Returns: Symbol if found, nullopt otherwise

Definition at line 238 of file symbol_provider.cc.

References symbols_by_name_.

Referenced by yaze::agent::EmulatorServiceImpl::ResolveSymbol().

◆ FindSymbolsMatching()

std::vector< Symbol > yaze::emu::debug::SymbolProvider::FindSymbolsMatching ( const std::string & pattern ) const

Find symbols matching a pattern (supports wildcards)

Parameters

pattern Pattern with * as wildcard (e.g., "Module*", "*_Init")

Returns: Matching symbols

Definition at line 247 of file symbol_provider.cc.

References symbols_by_name_.

Referenced by yaze::agent::EmulatorServiceImpl::ResolveSymbol().

◆ GetSymbolsInRange()

std::vector< Symbol > yaze::emu::debug::SymbolProvider::GetSymbolsInRange	(	uint32_t	start,
		uint32_t	end ) const

Get all symbols in an address range.

Definition at line 258 of file symbol_provider.cc.

References symbols_by_address_.

◆ GetNearestSymbol()

std::optional< Symbol > yaze::emu::debug::SymbolProvider::GetNearestSymbol ( uint32_t address ) const

Get nearest symbol at or before an address.

Useful for showing "MainGameLoop+$10" style offsets

Definition at line 269 of file symbol_provider.cc.

References symbols_by_address_.

Referenced by FormatAddress(), and yaze::agent::EmulatorServiceImpl::GetSymbolAt().

◆ FormatAddress()

std::string yaze::emu::debug::SymbolProvider::FormatAddress	(	uint32_t	address,
		uint32_t	max_offset = 0x100 ) const

Format an address with symbol info.

Returns formats like: "MainGameLoop" (exact match) "MainGameLoop+$10" (offset from nearest symbol) "$00804D" (no nearby symbol)

Definition at line 286 of file symbol_provider.cc.

References GetNearestSymbol(), and GetSymbol().

Here is the call graph for this function:

◆ GetSymbolCount()

size_t yaze::emu::debug::SymbolProvider::GetSymbolCount ( ) const

inline

Get total number of loaded symbols.

Definition at line 173 of file symbol_provider.h.

References symbols_by_address_.

Referenced by yaze::agent::EmulatorServiceImpl::LoadSymbols().

◆ HasSymbols()

bool yaze::emu::debug::SymbolProvider::HasSymbols ( ) const

inline

Check if any symbols are loaded.

Definition at line 178 of file symbol_provider.h.

References symbols_by_address_.

◆ CreateResolver()

std::function< std::string(uint32_t)> yaze::emu::debug::SymbolProvider::CreateResolver ( ) const

Create a symbol resolver function for the disassembler.

Definition at line 307 of file symbol_provider.cc.

References GetSymbolName().

Here is the call graph for this function:

◆ ParseAsarAsmContent()

absl::Status yaze::emu::debug::SymbolProvider::ParseAsarAsmContent	(	const std::string &	content,
		const std::string &	filename )

private

Definition at line 313 of file symbol_provider.cc.

References yaze::emu::debug::Symbol::address, AddSymbol(), yaze::emu::debug::Symbol::file, yaze::emu::debug::Symbol::is_local, yaze::emu::debug::Symbol::line, and yaze::emu::debug::Symbol::name.

Referenced by LoadAsarAsmFile(), and LoadSymbolFile().

Here is the call graph for this function:

◆ ParseWlaDxSymFile()

absl::Status yaze::emu::debug::SymbolProvider::ParseWlaDxSymFile ( const std::string & content )

private

Definition at line 390 of file symbol_provider.cc.

References AddSymbol().

Referenced by LoadSymbolFile().

Here is the call graph for this function:

◆ ParseMesenMlbFile()

absl::Status yaze::emu::debug::SymbolProvider::ParseMesenMlbFile ( const std::string & content )

private

Definition at line 431 of file symbol_provider.cc.

References AddSymbol().

Referenced by LoadSymbolFile().

Here is the call graph for this function:

◆ ParseBsnesSymFile()

absl::Status yaze::emu::debug::SymbolProvider::ParseBsnesSymFile ( const std::string & content )

private

Definition at line 459 of file symbol_provider.cc.

References AddSymbol().

Referenced by LoadSymbolFile().

Here is the call graph for this function:

◆ DetectFormat()

SymbolFormat yaze::emu::debug::SymbolProvider::DetectFormat	(	const std::string &	content,
		const std::string &	extension ) const

private

Definition at line 486 of file symbol_provider.cc.

References yaze::emu::debug::kAsar, yaze::emu::debug::kBsnes, yaze::emu::debug::kMesen, and yaze::emu::debug::kWlaDx.

Referenced by LoadSymbolFile().

Member Data Documentation

◆ symbols_by_address_

std::multimap<uint32_t, Symbol> yaze::emu::debug::SymbolProvider::symbols_by_address_

private

Definition at line 198 of file symbol_provider.h.

Referenced by AddSymbol(), Clear(), GetNearestSymbol(), GetSymbol(), GetSymbolCount(), GetSymbolName(), GetSymbolsAtAddress(), GetSymbolsInRange(), and HasSymbols().

◆ symbols_by_name_

std::map<std::string, Symbol> yaze::emu::debug::SymbolProvider::symbols_by_name_

private

Definition at line 201 of file symbol_provider.h.

Referenced by AddSymbol(), Clear(), FindSymbol(), and FindSymbolsMatching().

The documentation for this class was generated from the following files:

src/app/emu/debug/symbol_provider.h
src/app/emu/debug/symbol_provider.cc
