#include <metal_renderer.h>

Inheritance diagram for yaze::gfx::MetalRenderer:

Collaboration diagram for yaze::gfx::MetalRenderer:

Public Member Functions
	MetalRenderer ()=default

	~MetalRenderer () override

bool	Initialize (SDL_Window *window) override
	Initializes the renderer with a given window.

void	Shutdown () override
	Shuts down the renderer and releases all associated resources.

TextureHandle	CreateTexture (int width, int height) override
	Creates a new, empty texture.

TextureHandle	CreateTextureWithFormat (int width, int height, uint32_t format, int access) override
	Creates a new texture with a specific pixel format.

void	UpdateTexture (TextureHandle texture, const Bitmap &bitmap) override
	Updates a texture with the pixel data from a Bitmap.

void	DestroyTexture (TextureHandle texture) override
	Destroys a texture and frees its associated resources.

bool	LockTexture (TextureHandle texture, SDL_Rect rect, void pixels, int pitch) override

void	UnlockTexture (TextureHandle texture) override

void	Clear () override
	Clears the entire render target with the current draw color.

void	Present () override
	Presents the back buffer to the screen, making the rendered content visible.

void	RenderCopy (TextureHandle texture, const SDL_Rect srcrect, const SDL_Rect dstrect) override
	Copies a portion of a texture to the current render target.

void	SetRenderTarget (TextureHandle texture) override
	Sets the render target for subsequent drawing operations.

void	SetDrawColor (SDL_Color color) override
	Sets the color used for drawing operations (e.g., Clear).

void *	GetBackendRenderer () override
	Provides an escape hatch to get the underlying, concrete renderer object.

void	SetMetalView (void *view)

Public Member Functions inherited from yaze::gfx::IRenderer
virtual	~IRenderer ()=default

Private Attributes
void *	metal_view_ = nullptr

void *	command_queue_ = nullptr

TextureHandle	render_target_ = nullptr

Detailed Description

Definition at line 8 of file metal_renderer.h.

Constructor & Destructor Documentation

◆ MetalRenderer()

yaze::gfx::MetalRenderer::MetalRenderer ( )

default

◆ ~MetalRenderer()

yaze::gfx::MetalRenderer::~MetalRenderer ( )

override

Definition at line 22 of file metal_renderer.mm.

References Shutdown().

Here is the call graph for this function:

Member Function Documentation

◆ Initialize()

bool yaze::gfx::MetalRenderer::Initialize ( SDL_Window * window )

overridevirtual

Initializes the renderer with a given window.

Parameters

window A pointer to the SDL_Window to render into.

Returns: True if initialization was successful, false otherwise.

Implements yaze::gfx::IRenderer.

Definition at line 26 of file metal_renderer.mm.

References command_queue_, LOG_WARN, and metal_view_.

◆ Shutdown()

void yaze::gfx::MetalRenderer::Shutdown ( )

overridevirtual

Shuts down the renderer and releases all associated resources.

Implements yaze::gfx::IRenderer.

Definition at line 53 of file metal_renderer.mm.

References command_queue_, and render_target_.

Referenced by ~MetalRenderer().

◆ CreateTexture()

TextureHandle yaze::gfx::MetalRenderer::CreateTexture	(	int	width,
		int	height )

overridevirtual

Creates a new, empty texture.

Parameters

width	The width of the texture in pixels.
height	The height of the texture in pixels.

Returns: An abstract TextureHandle to the newly created texture, or nullptr on failure.

Implements yaze::gfx::IRenderer.

Definition at line 61 of file metal_renderer.mm.

References metal_view_.

Referenced by CreateTextureWithFormat().

◆ CreateTextureWithFormat()

TextureHandle yaze::gfx::MetalRenderer::CreateTextureWithFormat	(	int	width,
		int	height,
		uint32_t	format,
		int	access )

overridevirtual

Creates a new texture with a specific pixel format.

Parameters

width	The width of the texture in pixels.
height	The height of the texture in pixels.
format	The SDL pixel format (e.g., SDL_PIXELFORMAT_ARGB8888).
access	The texture access pattern (e.g., SDL_TEXTUREACCESS_STREAMING).

Returns: An abstract TextureHandle to the newly created texture, or nullptr on failure.

Implements yaze::gfx::IRenderer.

Definition at line 94 of file metal_renderer.mm.

References CreateTexture().

Here is the call graph for this function:

◆ UpdateTexture()

void yaze::gfx::MetalRenderer::UpdateTexture	(	TextureHandle	texture,
		const Bitmap &	bitmap )

overridevirtual

Updates a texture with the pixel data from a Bitmap.

Parameters

texture	The handle of the texture to update.
bitmap	The Bitmap containing the new pixel data.

Implements yaze::gfx::IRenderer.

Definition at line 102 of file metal_renderer.mm.

References yaze::platform::ConvertSurfaceFormat(), and yaze::gfx::Bitmap::surface().

Here is the call graph for this function:

◆ DestroyTexture()

void yaze::gfx::MetalRenderer::DestroyTexture ( TextureHandle texture )

overridevirtual

Destroys a texture and frees its associated resources.

Parameters

texture The handle of the texture to destroy.

Implements yaze::gfx::IRenderer.

Definition at line 136 of file metal_renderer.mm.

References render_target_.

◆ LockTexture()

bool yaze::gfx::MetalRenderer::LockTexture	(	TextureHandle	texture,
		SDL_Rect *	rect,
		void **	pixels,
		int *	pitch )

overridevirtual

Implements yaze::gfx::IRenderer.

Definition at line 150 of file metal_renderer.mm.

◆ UnlockTexture()

void yaze::gfx::MetalRenderer::UnlockTexture ( TextureHandle texture )

overridevirtual

Implements yaze::gfx::IRenderer.

Definition at line 159 of file metal_renderer.mm.

◆ Clear()

void yaze::gfx::MetalRenderer::Clear ( )

overridevirtual

Clears the entire render target with the current draw color.

Implements yaze::gfx::IRenderer.

Definition at line 163 of file metal_renderer.mm.

◆ Present()

void yaze::gfx::MetalRenderer::Present ( )

overridevirtual

Presents the back buffer to the screen, making the rendered content visible.

Implements yaze::gfx::IRenderer.

Definition at line 166 of file metal_renderer.mm.

◆ RenderCopy()

void yaze::gfx::MetalRenderer::RenderCopy	(	TextureHandle	texture,
		const SDL_Rect *	srcrect,
		const SDL_Rect *	dstrect )

overridevirtual

Copies a portion of a texture to the current render target.

Parameters

texture	The source texture handle.
srcrect	A pointer to the source rectangle, or nullptr for the entire texture.
dstrect	A pointer to the destination rectangle, or nullptr for the entire render target.

Implements yaze::gfx::IRenderer.

Definition at line 169 of file metal_renderer.mm.

References command_queue_, and render_target_.

◆ SetRenderTarget()

void yaze::gfx::MetalRenderer::SetRenderTarget ( TextureHandle texture )

overridevirtual

Sets the render target for subsequent drawing operations.

Parameters

texture The texture to set as the render target, or nullptr to set it back to the default (the window).

Implements yaze::gfx::IRenderer.

Definition at line 226 of file metal_renderer.mm.

References render_target_.

◆ SetDrawColor()

void yaze::gfx::MetalRenderer::SetDrawColor ( SDL_Color color )

overridevirtual

Sets the color used for drawing operations (e.g., Clear).

Parameters

color The SDL_Color to use.

Implements yaze::gfx::IRenderer.

Definition at line 230 of file metal_renderer.mm.

◆ GetBackendRenderer()

void * yaze::gfx::MetalRenderer::GetBackendRenderer ( )

overridevirtual

Provides an escape hatch to get the underlying, concrete renderer object.

This is necessary for integrating with third-party libraries like ImGui that are tied to a specific rendering backend (e.g., SDL_Renderer*, ID3D11Device*).

Returns: A void pointer to the backend-specific renderer object. The caller is responsible for casting it to the correct type.

Implements yaze::gfx::IRenderer.

Definition at line 234 of file metal_renderer.mm.

References command_queue_.

◆ SetMetalView()

void yaze::gfx::MetalRenderer::SetMetalView ( void * view )

Definition at line 238 of file metal_renderer.mm.

References metal_view_.

Referenced by yaze::platform::IOSWindowBackend::InitializeRenderer().

Member Data Documentation

◆ metal_view_

void* yaze::gfx::MetalRenderer::metal_view_ = nullptr

private

Definition at line 36 of file metal_renderer.h.

Referenced by CreateTexture(), Initialize(), and SetMetalView().

◆ command_queue_

void* yaze::gfx::MetalRenderer::command_queue_ = nullptr

private

Definition at line 37 of file metal_renderer.h.

Referenced by GetBackendRenderer(), Initialize(), RenderCopy(), and Shutdown().

◆ render_target_

TextureHandle yaze::gfx::MetalRenderer::render_target_ = nullptr

private

Definition at line 38 of file metal_renderer.h.

Referenced by DestroyTexture(), RenderCopy(), SetRenderTarget(), and Shutdown().

The documentation for this class was generated from the following files:

src/app/gfx/backend/metal_renderer.h
src/app/gfx/backend/metal_renderer.mm
